TP-LINK Router VPN AX3000 4G/LTE ER706W-4G

TP-LINK Router VPN AX3000 4G/LTE ER706W-4G

Model:

ER706W-4G

Description:

Omada Gigabit VPN Router, 4G+ Cat6, AX3000

• 4G+ Cat6 modem: Insert a Nano SIM card and use the cellular network with speeds up to 300 Mbps.
• Dual-band WiFi 6, AX3000: Up to 2402 Mbps on the 5 GHz band and up to 574 Mbps on the 2.4 GHz band.
• 6 Gigabit Ethernet ports: High-speed wired connections.
• 5 efficient, detachable antennas: 2 LTE antennas and 3 dual-band WiFi antennas.
• Centralized management: Access from the Cloud and the Omada application provides convenient management.
• Omada Mesh: Seamlessly connect Mesh-enabled EAPs.
• Secure VPN: The router supports multiple VPN protocols, including IPSec, SSL, Wireguard, OpenVPN, PPTP, L2TP.

Type: GSM 3G/4G
Data transmission: HSUPA
Data transmission: LTE
I/O ports: 4 x 10/100/1000 Mbit/s
Data transmission: HSPA+
Data transmission: UMTS
Data transmission: HSDPA
I/O ports: 1 x WAN (RJ-45)
I/O ports: 1 x SFP
LTE network: 2600 MHz
LTE network: 900 MHz
LTE network: 850 MHz
LTE network: 2500 MHz
LTE network: 1800 MHz
LTE network: 2100 MHz
LTE network: 2300 MHz
Aero2 support: No
Standards: 802.1Q
Operating frequency: 5 GHz
Operating frequency: 2,4 GHz
Number of antennas: 5
Antenna: Detachable external
Antenna gain: 4.5 dBi
Management, monitoring, configuration:
Security:

Access control

• Access control based on source/destination IP address

Filtration

• WEB group filtering
• URL filtering
• Network security

Protection against ARP attacks

• Sending GARP packets
• ARP scanning
• IP and MAC address binding

Protection against network attacks

• TCP/UDP/ICMP Flood Defense
• TCP Scan Blocking (Stealth FIN/Xmas/Null)
• Blocking the reception of ping packets from the WAN network

Special functions:
SIM card: Nano
Power supply:

Power supply 12V/2A (DC)

Software:
Certificates:

• CE,
• FCC,
• RoHS

Supported operating systems: Linux
Supported operating systems: Unix
Supported operating systems: Novell NetWare
Supported operating systems: Mac OS
Supported operating systems: Windows 98 SE
Supported operating systems: Windows NT
Supported operating systems: Windows 2000
Supported operating systems: Windows XP
Supported operating systems: Windows Vista
Supported operating systems: Windows 7
Supported operating systems: Windows 8
Supported operating systems: Windows 8.1
Supported operating systems: Windows 10
Supported operating systems: Windows 11
System Requirements:
Environment requirements:

• Permissible operating temperature: 0-40 degrees Celsius
• Permissible storage temperature: -40-70 degrees Celsius
• Permissible air humidity: 10-90%, no condensation
• Permissible storage humidity: 5-90% without condensation

Accessories included:

• Charger
• Quick installation guide

Color: Black
Dimensions:

226 × 131 × 35 mm

Other features:
Designation:
