Intellinet Switch Gigabit 48-ports managed RJ45 4x SFP

Intellinet Switch Gigabit 48-ports managed RJ45 4x SFP

Description:

48-port Gigabit RJ45 4x SFP managed switch

Switch class: Managed
Application: Medium and large companies
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 48
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: None
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: None
Number of COMBO ports: None
Number of SFP ports: 4
Number of SFP+ ports: None
Number of SFP56 ports: None
Number of QSFP+ ports: None
Console port: No
Forwarding mode: Store-and-forward
Throughput: 104 Gigabity na sek.
Memory buffer: 1500 Kilobajt
MAC address table size: 8000
Support for Jumbo frames: Yes
Jumbo frame size: 9 Kilobajt
Stackability: No
VLAN:

VLAN support based on tags or ports (tag-based, port-based)

Supported protocols and standards:

• IEEE 802.1d (Spanning Tree protocol)
• IEEE 802.1p (Traffic Prioritization)
• IEEE 802.1q (VLAN Tagging)
• IEEE 802.1s (Spanning Tree Protocol (MSTP)
• IEEE 802.3ad (Link Aggregation)
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3ab (Gigabit Ethernet Twisted Pair)
• IEEE 802.3ad (Link Aggregation Control LACP Protocol)
• IEEE 802.3az (Energy Efficient Ethernet EEE)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3x (Flow control, full duplex)
• SNMPv1/v2 (Simple Network Management Protocol)

QoS:

Support for two types of QoS: port-based and DSCP

Security:
Management, monitoring, configuration:

• Bandwidth management for all ports
• SNMP management and remote RMON monitoring

L2 features:
L3 features:
Other functions:
Chassis type: Rack
Fan : No
Power supply : External
Power consumption: 36 Watt
Environment requirements:

• Operating temperature: 0 – 40°C
• Operating humidity: 10% – 90% RH, non-condensing
• Storage temperature: -20 – 70°C

Certificates:

• FCC Class A,
• CE

Accessories included:

• 48-Port Managed Gigabit Ethernet Switch with 4 SFP Slots
• Power cable
• User manual
• 19″ mounting brackets

Power supply:

Input voltage: 100 – 240 V AC, 50 – 60 Hz

Dimensions:

335 x 440 x 44 mm

Weight: 4.2 kilogram
Other features:
Designation:
