Zyxel 5G NR Indoor Router FWA505 Standalone/Nebula with 1 yearNebula Pro License, AX1800 WiFi, 1 x GB LAN, EU region

Zyxel 5G NR Indoor Router FWA505 Standalone/Nebula with 1 yearNebula Pro License, AX1800 WiFi, 1 x GB LAN, EU region

Model:

FWA505

Description:

Nebula 5G NR Indoor Router FWA505

Supercharge your Internet with 5G Wireless Access

Meet the FWA505: the versatile 5G NR indoor router. Supercharge your connection in various scenarios with wireless simplicity, uninterrupted network and cost-effective solution. Boost your productivity with hassle-free, professional support!

Unlock the brilliance of 5G broadband

Experience seamless connectivity and cost-effectiveness with our FWA505 5G router:

• Cost-effective mobile Internet: The FWA505 surpasses mobile Internet sharing for tenants with better performance, heat dissipation and stability. It is also more cost-effective than wired Internet setups, eliminating the need for wired networks while providing excellent speed.
• Optimized Device Connectivity: Wi-Fi 6 optimized for up to 64 devices
• Diversified Network Allocations: 5GHz and 2.4GHz options for optimal network allocation
• Commercial-Grade Connectivity: True commercial-grade 5G router with dual Gigabit Ethernet LAN ports for switches, APs, computers, etc.

Anytime, Anywhere with Nebula Mobile App

FWA505 simplifies tasks – quick setup, no IT expertise required. Smooth cloud management via app provides a better experience.

• Easy device deployment with QR code scanning and setup wizard
• Network and device status at a glance
• Wi-Fi sharing via QR code or mobile apps
• Web client access control
• Live troubleshooting tools
• Push notifications for abnormal network events

Unleash the power of 5G and Wi-Fi 6

Experience seamless connectivity with FWA505. It offers plug-and-play convenience, using the power of 5G and Wi-Fi 6 to replace traditional wired connections. Say goodbye to laggy home networks and enjoy smooth conference calls and live streaming for SOHO and business.

Moreover, as an on-the-go networking solution, it is ideal for temporary needs such as construction sites, exhibitions, and pop-up stores. Saving valuable time on setup.

Basic security for easy protection:

• Multiple/Hidden SSIDs
• NAT/NAPT Firewall
• DoS Detection
• WPA2 and WPA3
• URL Filtering
• Application-Level Firewall
• LAN MAC Filtering
• IP Filtering
• WLAN MAC Filtering
• Stateful Packet Inspection (SPI)

Type: v
Type: GSM 3G/4G
Data transmission: LTE
LTE network: 2600 MHz
LTE network: 700 MHz
LTE network: 1800 MHz
LTE network: 800 MHz
LTE network: 850 MHz
LTE network: 900 MHz
LTE network: 3600 MHz
LTE network: 2100 MHz
LTE network: 2300 MHz
LTE network: 2500 MHz
LTE network: 3400 MHz
Aero2 support: No
Standards: IPv6
Standards: IPv4
Standards: 802.11a
Standards: 802.11b
Standards: 802.11g
Standards: 802.11n
Standards: 802.11ac
Standards: 802.11ax
Operating frequency: 2,4 GHz
Operating frequency: 5 GHz
Number of antennas: 5
Number of antennas: Two connectors
Antenna: Built-in
Antenna gain: 5 dBi
Management, monitoring, configuration:

IP Network:

• Support IPv4/IPv6 Dual Stack (NDP IPv6)
• DHCP Client/Server
• Virtual Private Network (VPN) Switching
• NAT/NAPT Support
• DMZ Support
• Multiple APN Support
• Port Forwarding Support

Routing:

• Support Bridge and Router Modes
• Support Remote Management in Bridge Mode
• Static/Dynamic Route Setting

IP Firewall:

• DoS Detection
• SPI Support
• Application-level firewall (LAN to WAN, such as FTP, HTTP, Telnet, Ping)
• LAN MAC Address Filtering
• LAN IP Address Filtering

Management:

• Supports local/remote device management and firmware upgrade via TR-069 and web GUI
• PIN/PUK Management
• Management APN
• Working Band Selection
• CLI/SSH (Local and Remote SSH Access)
• UPnP IGD Support
• Supports Web Server API for Application Support
• Zyxel Nebula App Support (iOS and Android) for Easy Installation and Local Management

WLAN Function:

• Automatic Channel Selection
• Wi-Fi Protected Setup (WPS)
• Wi-Fi Multimedia (WMM)
• Wi-Fi Enabled Devices: Up to 64
• MAC Address Filtering with 64 Addresses Support
• Multiple SSIDs/SSID Hiding
• WLAN Planning

Security:

• WPA2-Personal, WPA/WPA2, WPA3
• DoS Attack Detection
• SPI Support
• Application-level firewall (LAN to WAN, e.g. FTP, HTTP, Telnet, Ping)
• LAN MAC filtering
• LAN IP filtering

Special functions:
Card reader: None
Memory standard: Not applicable
I/O ports: 1 x SIM card slot
I/O ports: 1 x 10/100/1000 Mbit/s
I/O ports: 1 x USB 2.0 Type A
I/O ports: 1 x 10/100/1000 Mbit/s LAN / WAN (Combo)
SIM card: Micro
Power supply:

AC adapter

Software:
Certificates:

• CE
• NCC
• BSMI
• NBTC Certificate

Supported operating systems: Android
Supported operating systems: iOS
System Requirements:
Environment requirements:

• Ambient operating temperature: -10°C to 40°C (14°F to 104°F)
• Ambient operating humidity: 10% to 90% RH (non-condensing)
• Ambient storage temperature: -30°C to 70°C (-22°F to 158°F)
• Ambient storage humidity: 0% to 95% (non-condensing)

Accessories included:

• Power Supply
• Ethernet Cable 1.8m 8P8C
• Nebula Pro License Pack 1 Year

Color: White
Weight: 1145 gram
Dimensions:

103 x 103 x 222 mm

Other features:

5G NR Interface:

• 3GPP Release 15 Compliant
• DL 4×4 MIMO Support: n1/n3/n7/n38/n40/n41/n77/n78
• DL QPSK, 16-QAM, 64-QAM and 256-QAM Modulation Support
• UL QPSK, 16-QAM, 64-QAM and 256-QAM Modulation Support
• NSA and SA Mode Support
• Data Rate: 5G SA: DL 4.7 Gbps, UL 2.5 Gbps / 5G NSA: DL 3.7 Gbps, UL 1.5 Gbps
• Output Power: Class 2 (26 dBm) for 5G NR n41/n77/n78 / Class 3 (23 dBm) for other FDD/TDD NR bands

4G LTE Interface:

• Compliant with 3GPP EU Category 19
• Supports DL 4×4 MIMO: B1/B3/B7/B38/B40/B41/B42/B43
• Supports DL QPSK, 16-QAM, 64-QAM and 256-QAM modulation
• Supports UL QPSK, 16-QAM, 64-QAM and 256-QAM modulation
• Peak Data Rate: Max. DL 1.6 Gbps/UL 211 Mbps
• Output Power: Class 3 (23 dBm +/-2 dBm) for other FDD/TDD LTE bands

Designation:
