UBIQUITI USW-Pro-Max-24 Switch Pro Max 24

UBIQUITI USW-Pro-Max-24 Switch Pro Max 24

Description:

UBIQUITI USW-Pro-Max-24
The Pro Max 24 (USW-Pro-Max-24) is a 24-port Layer 3 Etherlighting switch that offers 2.5GbE throughput. Etherlighting ports are illuminated for easy port location, speed/link information, and native VLAN/network*. It features 8 x 2.5GbE RJ45 ports, 16 x GbE RJ45 ports, and 2 x 10G SFP+ ports. Powered by a ready-made DC backup power supply. Managed via UniFi Network 8.0.24 and later. *For optimal brightness, pairing with UniFi Etherlighting patch cables is recommended.

Switch class: Managed
Application: Medium and large companies
Switch layer: L3
Switch layer: L2
Network architecture: GigabitEthernet
Number of 10/100/1000 Mbps ports: 16
10/100/1000/2500 Mbps ports: 8
Number of SFP+ ports: 2
Console port: No
Throughput: 112 Gigabity na sek.
Forwarding rate: 83.328 Mpps
Support for Jumbo frames: Yes
VLAN:
Supported protocols and standards:
QoS:
Security:
Management, monitoring, configuration:
L2 features:

• IGMP snooping
• STP / RSTP with priorities and port-level disable
• Port isolation
• Storm control
• Voice VLAN
• Port mirroring
• LACP port aggregation
• Multicast / broadcast rate limiting
• MAC address blocking
• Flow control
• 802.1X control
• Jumbo frames
• Proprietary loop protection
• DHCP snooping / guarding
• Egress rate limit
• LLDP-MED
• Port restricted by MAC
• Device isolation with ACLs

L3 features:

• DHCP for locally-managed networks
• DHCP relay
• Inter-VLAN routing between networks on same switch
• Static routing between local networks
• Network isolation with ACLs

Other functions:
Chassis type: Rack
Fan : No
Power supply : Internal
Power consumption: 50 Watt
Environment requirements:
Certificates:

• CE
• FCC
• IC

Accessories included:
Power supply:

• Universal Input, 100240 VAC, 50/60 Hz
• UniFi SmartPower RPS DC Input

Dimensions:

442.4 x 325 x 43.7 mm

Weight: 4.2 kilogram
Other features:
Designation:
