Описание:

Omada Managed L3 Aggregation Switch, Stackable, 26 SFP+ 10G Slots, 6 SFP28 25G Slots

• 26 SFP+ 10G Slots, 6 SFP28 25G Slots
• 820 Gbps Switching Capacity
• Physical Stacking for Redundancy and Better Performance
• L3 Features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay
• Security Strategies: ACL, Port Security, DoS Protection, 802.1X
• Increased Availability with Dual Power Supplies*, VRRP, and ERPS
• Centralized Cloud Management via Omada SDN Controller
• Autonomous Management via Web Interface, CLI, SNMP, RMON

*The switch ships with one PSM550-AC захранващ блок Module. If you wish to utilize the second захранващ блок slot, you must purchase an additional захранващ блок separately.

Product Applications
The Omada SX6632YF is a managed Layer 3 switch with fiber ports that offers L3 routing, high-speed 25 Gbps wire speed, stacking, and redundant захранващ блок to meet the needs of the convergence layer. It is equipped with six 25 Gbps SFP28 slots, 26 10 Gbps SFP+ slots, and physical stacking capabilities. High-level security and advanced management features ensure this switch provides reliable performance for SMB, enterprise, and ISP applications.

High Speed and Efficient Stacking
Six 25 Gbps SFP28 slots and 26 10 Gbps SFP+ slots provide up to 820 Gbps of switching capacity per unit. Physical stacking of up to 8 units and a combined switching speed of up to 6560 Gbps strengthens the network fabric with its performance and built-in redundancy.

Extensive Layer 3 Capabilities
The switch features multiple Layer 3 routing protocols to support network scalability. Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and DHCP Relay are supported. The PIM-DM multicast routing protocol ensures efficient routing for multicast groups.

High Availability
Redundant power* and VRRP are ideal for a reliable network architecture. ERPS supports rapid protection and recovery in a ring topology.

Advanced Security Features
ACLs (IPv4 and IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell (SSH) protect the network against a wide range of threats.

Omada SDN
The Omada system offers centralized cloud management and numerous management features, such as Zero-Touch Provisioning (ZTP)*. The Omada software-defined network infrastructure (SDN) platform integrates network devices, including access points, switches, and gateways, providing completely centralized cloud management from a single interface.

In addition to centralized management via the Omada app, the SX6632YF switch can also be easily managed via a web configuration page or command line interface (CLI). Both methods protect traffic using SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON enable polling of the switch to obtain valuable information and send traps in the event of unexpected events.
