TP-LINK System WiFi Deco S7(1-pack) AC1900

TP-LINK System WiFi Deco S7(1-pack) AC1900

Model:

DECO S7

Description:

Home Wi-Fi Mesh System, AC1900

• Fast Wi-Fi – Watch your favorite series in 4K resolution with total wireless speeds of up to 1900 Mbps (600 Mbps on the 2.4 GHz band and 1300 Mbps on the 5 GHz band) and MU-MIMO 3 technology ×3.
• Connect over 100 devices – The Deco system can handle traffic even in the busiest networks, providing lag-free connections for over 100 devices.
• Enhanced Wi-Fi Signal – Thanks to advanced Deco Mesh technology, system units work together to create a unified network. Your devices will automatically connect to Deco offering the best signal as you move around your home.
• Gigabit ports – 3 Gigabit Ethernet WAN/LAN ports provide fast and stable Internet access.
• Extensive Parental Controls – Limit time spent online and block inappropriate websites based on the profiles you create for each family member.
• Two operating modes – The Deco system can operate as a Router or access points.
• Easy configuration – The Deco application will guide you step by step through the entire configuration process.

Wi-Fi dead zone killer

Deco S7 is the easiest way to have a strong wireless signal throughout your home. One Deco device covers an area of up to 190 m2 with a wireless network. Wireless connections and optional Ethernet backhaul connect Deco units for even faster speeds and unprecedented switching smoothness. Need more Wi-Fi coverage? Just add another Deco unit.



Smooth and fast switching

TP-Link Mesh technology makes Deco units work together to create a unified Wi-Fi network. When moving around the house, your phone or tablet will always connect to the Deco unit that offers it the best connection, without interrupting the transfer.

Two operating modes: Router and Access Point

The multifunctional and flexible Deco S7 device can operate in both router and access point mode. Choose the mode appropriate to your current network requirements and enjoy all the possibilities of a wireless network.

Simplified Wi-Fi access

• Configuration via app – Installing Deco S7 is quick and simple. Unpack your devices, install the app, and then follow the on-screen instructions.
• Simple management – With the Deco application you can manage your network from home or remotely. The application allows, among other things, verification of connected devices, assigning them priorities, and configuring the network for guests in a few simple steps.
• Voice Control – Pair Deco S7 with Alexa and control the device with simple voice commands.

Reliable parental controls

The simple and intuitive parental control function will make it easy for you to provide your child with comprehensive online protection.

Works with all Deco models

Deco S7 can create a mesh network with any other Deco model. To increase the range of the network, simply add another Deco unit to it.

Type: xDSL
Network architecture: GigabitEthernet
I/O ports: 3 x 10/100/1000 Mbit/s
Standards: 802.11a
Standards: IPv6
Standards: IPv4
Standards: 802.11ac
Standards: 802.11g
Standards: 802.11b
Standards: 802.11n
Operating frequency: 5 GHz
Operating frequency: 2,4 GHz
Number of antennas: 3
Antenna: Built-in
Security:

Network protection:

• SPI Firewall
• Access control

Guest Network Feature:

• 5 GHz guest network
• 2.4 GHz guest network

WiFi network encryption:

• WPA-Personal
• WPA2-Personal

Management, monitoring, configuration:

Modes of operation:

• Router mode
• Access point mode

Parental Control:

• Website address filtering
• Access limits

WAN:

• Dynamic IP address allocation
• Static IP address allocation
• PPPoE
• PPTP
• L2TP

Quality of Service: QoS priorities for devices

Cloud service:

• OTA software updates
• TP-Link ID
• DDNS

NAT redirection:

• Port forwarding
• UPnP

IPTV:

• IGMP Proxy
• IGMP Snooping
• Bridge
• VLAN tagged

DHCP:

• Address reservation
• DHCP client list
• Server

DDNS: TP-Link

Special functions:
Power supply:
Software:

Deco application

Supported operating systems: Android
Supported operating systems: iOS
System Requirements:
Environment requirements:

• Permissible operating temperature: 0~40C (32 ~104F)
• Permissible storage temperature: -40~70C (-40 ~158F)
• Permissible air humidity: 10%~90%, no condensation
• Permissible storage humidity: 5%~90%, non-condensing

Certificates:

• CE
• FCC
• RoHS
• NCC
• BSMI
• JRF
• JPA
• VCC

Accessories included:

• Deco S7 unit
• RJ45 Ethernet cable
• Charger
• Quick installation guide

Color: White
Dimensions:

162.3 × 90.7 × 90.7 mm

Other features:

Reset button

AC1900 WiFi speeds:

• 5GHz: 1300Mbps (802.11ac)
• 2.4GHz: 600Mbps (802.11n)

WiFi CE transmission power:

• < 20 dBm (2.4 GHz)
• < 23 dBm (5 GHz)

Designation:
