TP-LINK Module SM5310-T SFP+ 10G BASE-T RJ45

TP-LINK Module SM5310-T SFP+ 10G BASE-T RJ45

Description:

SFP+ 10G BASE-T RJ45 module

• Supports 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T and 100BASE-TX operations
• 10Gb/s data transmission up to 30m* (UTP cat.6a or higher cable)
• Support for DDM (Temperature and Voltage) function
• Hot-Plug SFP+ Footprint function
• TX function disable support
• Commercial product operating temperature range: 0-70°C
• All-metal housing for low EMI

Product application

The TL-SM5310-T provides superior 10G performance with a simple and fast combination of SFP+ interface and RJ45 port. It offers a range of up to 30m at 10Gbps (UTP cat.6a or higher cable). Plug-and-Play operation enables easy installation and does not require calling in a specialist. The high-quality metal housing ensures durability and reliability over a long period of time, while maintaining stable performance over a wide range of environmental factors.

Form factor: SFP+
Range: 30 m
Fiber type: Single-mode
Max transmission speed: 10 Gigabajty na sek.
Accessories included:

• TL-SM5310-T Module
• Installation manual

Other features:

Network card

• Standards and protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
• Power supply: 3.3V
• Max. cable length: 100BASE-TX: UTP cat .5 or higher (max. 100m), 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or higher (max. 100m), 10GBASE-T: UTP cat.6a or higher (max. 30m)
• Transmission speed: 10.3 Gbps
• Port type: 1 RJ45 10G port
• Certifications: FCC, CE, RoHS
