TP-LINK EAP113-Outdoor Access Point N300

TP-LINK EAP113-Outdoor Access Point N300

Description:

EAP113-Outdoor

Wireless, outdoor access point, N300 standard

• Perfect for outdoor environments: The access point has an IP65-rated housing.
• Fast Wi-Fi: Wi-Fi speeds reach up to 300Mbps thanks to 2×2 MIMO technology.
• Long range: High-power amplifier and professional antennas.
• Omada SDN Integration: Centralized Cloud Management and Intelligent Monitoring.
• Central management: Cloud access and the Omada application ensure easy and convenient management.
• PoE support: Support of the 802.3af standard and 48V Passive PoE allows easy installation.
• Secure Guest Network: Multiple access authentication methods (SMS/Voucher, etc.) and extensive wireless security technologies.

Top-class design

Thanks to the well-thought-out design of the housing, antennas and flexible power supply and installation options,

EAP113-Outdoor is perfect for both inside and outside any building.



Detachable antennas

EAP113-Outdoor has two detachable omnidirectional antennas, which allows them to be easily replaced if necessary.

Long-distance data transmission

High transmission power and two powerful omnidirectional antennas make EAP113-Outdoor provide a stable wireless network

with a range of up to 200m when located outside the building.

Waterproof case designed for outdoor environments

The IP65 certificate obtained during testing guarantees that the access point will withstand even the harshest weather conditions.

Integration with the Omada SDN platform

The Omada Software Defined Networking (SDN) platform integrates network devices such as Access Points, Switches and Routers to provide 100% centralized cloud management and a highly scalable network managed from a single interface.

Easy management with the Omada app

With easy-to-follow instructions, it only takes a few minutes to configure the settings you need in the Omada app. Monitor the network status, manage clients, change settings at any time, all from your smartphone or tablet.

Network architecture: GigabitEthernet
I/O ports: 1 x 10/100/1000 Mbit/s
Operating frequency: 2,4 GHz
Standards: 802.11b
Standards: 802.11g
Standards: 802.11n
Number of antennas: 2
Antenna: Detachable external
Antenna gain: 3 dBi
Security:

• Authentication via welcome page
• Access control
• MAC address filtering
• Isolation of wireless clients
• SSID to VLAN mapping
• Unauthorized AP detection
• 802.1X support
• 64/128/152-bit WEP/WPA/WPA2-Enterprise, WPA-PSK/WPA2-PSK encryption

Management, monitoring, configuration:

• Omada app
• Central management
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada software controller
• Cloud Access – Requires the use of an OC300, OC200, or Omada Software Controller.
• Email notifications
• Diode switch
• Access control by MAC addresses
• SNMP v1, v2c
• System log – Local and remote
• SSH
• Browser management – HTTP/HTTPS
• L3 Management
• Multi-site management
• VLAN management

Special functions:

• Multi-SSID (Up to 8 SSIDs)
• On/Off wireless network
• Automatic channel selection
• Transmission power control
• QoS (WMM)
• Band balancing
• Bandwidth control
• Restart schedule
• Wireless network schedule
• Wireless statistics based on SSID/AP/client

Power supply:

• 48V Passive PoE (pins +4.5, pins -7.8)
• 802.3af PoE

Software:
System Requirements:

• Microsoft Windows XP
• Vista
• Windows 7
• Windows 8
• Windows 10
• Windows 11
• Linux

Environment requirements:

• Permissible operating temperature: -30°C – 65°C
• Permissible storage temperature: -40°C~70°C
• Permissible air humidity: 10% ~ 90%, non-condensing
• Permissible storage humidity: 5%~95%, non-condensing

Certificates:

• CE
• FCC
• RoHS

Accessories included:

• EAP110-Outdoor
• Mounting kit
• Waterproof rubber insert
• Waterproof antennas
• Quick installation guide

Color: White
Dimensions:

214.9 × 46 × 37.7 mm

Other features:
Designation:
