TP-LINK Access Point EAP613 AX1800

TP-LINK Access Point EAP613 AX1800

Description:

EAP613 AX1800 Standard Dual Band Wireless Ceiling Mount Access Point



• Lightning-fast Wi-Fi 6 speeds: Simultaneous support for speeds of up to 574 Mbps on the 2.4 GHz band and 1201 Mbps on the 5 GHz band for a total of up to 1775 Mbps.
• High-performance Wi-Fi 6: Connect more devices at high speeds.
• Centralized management: Management is extremely convenient thanks to cloud access and the easy-to-use Omada application.
• Seamless roaming: Video streams and ongoing voice calls are not interrupted when users change location.
• Omada Mesh: The ability to wirelessly connect APs to maintain large network coverage and location flexibility
• Support for PoE+ power supply: Selection of the location for the device and its installation do not cause any major difficulties thanks to the support for PoE+ power supply (802.3at standard) and DC power supply (power adapter not included).
• Compact Design: Dimensions 160mm x 33.6mm and elegant design.
• Secure guest network: Multiple authentication methods are available (SMS/Facebook Wi-Fi/Voucher, etc.) and numerous technologies that protect access to wireless networks.



AX1800 WiFi 6



• 574 Mbps in the 2.4 GHz band
• 1201 Mbps in the 5 GHz band



High-performance WiFi 6

More connected devices, faster speed.

Centralized management in the Cloud

Manage your network locally and remotely via the Cloud.

Seamless Roaming

Uninterrupted streaming while moving between access points.

Omada Mesh technology

Convenient and flexible wireless network deployment.

PoE+ powered

Supports 802.3at PoE+, Passive PoE and DC power (power adapter not included).

Compact design

Dimensions 160 mm × 33.6 mm and elegant design.

Gigabit Ethernet

Increases overall throughput with a Gigabit Ethernet port.

Powerful WiFi

Portal Authentication, MU-MIMO, Band Steering, Airtime Fairness and Load Balancing.

Lightning-fast speeds with Wi-Fi 6

Upgrade your wireless network to WiFi 6 with speeds up to 1775Mbps. Every online activity will be noticeably smoother.

Integration with the Omada SDN platform

The Omada Software Defined Networking (SDN) platform integrates network devices such as Access Points, Switches and Routers to provide 100% centralized cloud management and a highly scalable network managed from a single interface

Automatic Channel Selection and Power Control optimize performance

Provides high wireless performance while reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring access points on the same network.

Simple installation and high efficiency thanks to Omada Mesh

Easy pairing, less wires

Based on Mesh technology, Omada EAPs require no additional wires by wirelessly forwarding your WiFi signal for easy installation in places where cables are difficult to route.

Network performance optimization

Smart optimization chooses the best path between EAP APs, and Self-healing ensures they stay online even if one AP goes down.

Seamless switching with Fast Roaming

It provides users with uninterrupted streaming when they move nearby by automatically switching their devices to access points with optimal signal.

Ultra-compact design

Outstanding performance and compact design ensure simple WiFi installation while saving space. The elegant design makes the EAP613 a perfect fit for any modern office, hotel, classroom and coffee shop.

Increased network security and performance

Secure guest network with up to 16 SSIDs

The guest network provides enhanced security for users. Different SSIDs allow for easy management.

Guest network with Facebook WiFi and SMS login

A welcome page (including SMS, Facebook WiFi and Voucher) and 802.1x authentication help keep guests authorized and online. Grow your business with a custom advertising page.

WPA3 for open public networks

With advanced enterprise-grade security, WPA3 provides enhanced data security for hitherto unsecured WiFi hotspots.

Band steering

Dual-band devices are automatically connected to the wider 5GHz band, giving them access to faster connections.

Bandwidth load balancing

A heavily trafficked network works smoothly and without interruption even when many devices are connected to it.

Airtime Fairness

Improves network performance by reducing inefficient use of bandwidth.

Network architecture: GigabitEthernet
I/O ports: 1 x 10/100/1000 Mbit/s PoE
Operating frequency: 2,4 GHz
Operating frequency: 5 GHz
Standards: 802.11a
Standards: 802.11ac
Standards: 802.11ax
Standards: 802.3at
Standards: 802.1x
Standards: 802.11n
Standards: 802.11b
Standards: 802.11g
Number of antennas: 4
Antenna: Built-in
Antenna gain: 5 dBi
Security:

• Welcome page authentication
• Access control
• MAC address filtering
• Isolation of clients connected to the wireless network
• SSID to VLAN mapping
• Detection of unauthorized APs
• 802.1X support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise encryption

Management, monitoring, configuration:

• 1024-QAM
• 4 times longer OFDM symbol
• OFDMA
• Multi-SSID (up to 16 SSIDs, 8 for each band)
• On/Off wireless transmission
• Automatic channel selection
• Transmission power control (based on dBm)
• QoS (WMM)
• MU-MIMO
• Seamless roaming
• Omada Mesh§
• Band steering
• Bandwidth load balancing
• Airtime Fairness
• Beamforming
• Speed limiting
• Reboot schedule
• Wireless scheduler
• Wireless statistics based on SSID/AP/client
• Email notifications
• Diode switch
• Access control by MAC addresses
• SNMP: v1, v2c, v3
• System log: Local and remote
• SSH
• Web Based Management: HTTP/HTTPS
• L3 management
• Multi-site management
• VLAN management
• Unattended ZTP Setup – Requires the use of the Cloud-based Omada Controller

central management:

• Omada Cloud based controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada software controller

Cloud access via:

Omada Cloud based controller

• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada software controller

Special functions:
Power supply:

• 802.3at PoE
• 48V Passive PoE
• 12 V / 1 A DC (Power adapter NOT included)
• Power consumption: 11.0W (PoE), 9.9W (DC)

Software:

Omada app

System Requirements:

Compatible operating systems: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Accessories included:

• EAP613
• Mounting kit
• Installation Guide

Color: White
Dimensions:

160 x 160 x 33,6 mm

Environment requirements:

• Allowable operating temperature: 0-40 C (32104 F)
• Storage Temperature: -40-70 C (-40,158 F)
• Permissible air humidity: 10%-90%, non-condensing
• Permissible storage humidity: 5%-90%, non-condensing

Certificates:

• CE
• FCC
• RoHS

Other features:

• Reset button
• Ceiling/wall mount (mounting kit included)
• Mounting on a junction box

Transmission speed:

• 5GHz: Up to 1201Mbps
• 2.4GHz: Up to 574Mbps
