TELTONIKA Router LTE RUTXR1 (Cat6), 5xGbE WiFi, SFP

TELTONIKA Router LTE RUTXR1 (Cat6), 5xGbE WiFi, SFP

Model:

RUTXR1

Description:

RUTXR1

RUTXR1 is our first-ever rack-mount LTE Cat6 router with redundant power supplies and WAN interfaces that can be conveniently placed in a server rack. It is equipped with dual SIM, USB and Wave-2 802.11ac Dual Band WIFI. However, what distinguishes this product from other Teltonika Networks products are SFP WAN ports and dedicated console ports. A unique set of features allows it to be used as a basic product in a small or home office with LTE backup, efficient WiFi and no need to use an additional SFP to Ethernet конвертор.

This feature-rich device is powered by RutOS and is an excellent choice where a fast and ultra-reliable connection is required.

Type: GSM 3G/4G
Data transmission: LTE
Data transmission: UMTS
UMTS network: 900 MHz
UMTS network: 2100 MHz
UMTS network: 850 MHz
UMTS network: 1800 MHz
LTE network: 2600 MHz
LTE network: 1800 MHz
LTE network: 2100 MHz
LTE network: 2300 MHz
LTE network: 2500 MHz
LTE network: 700 MHz
LTE network: 800 MHz
LTE network: 850 MHz
LTE network: 900 MHz
LTE network: 1500 MHz
Aero2 support: No
Standards: 802.3u
Standards: 802.3
Standards: 802.11b
Standards: 802.11g
Standards: 802.11n
Standards: 802.11ac
Standards: 802.11e
Standards: 802.11r
Standards: 802.3az
Operating frequency: 2,4 GHz
Operating frequency: 5 GHz
Number of antennas: Four connectors
Antenna: Detachable external
Security:

• Authentication: Pre-shared key, digital certificates, X.509 certificates
• Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T
• Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN,
• SYN-RST, X-mas, NULL flags, FIN scan attacks)
• VLAN: Port and tag based VLAN separation
• Mobile quota control: Custom data limits for both SIM cards
• WEB filter: Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
• Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
• WiFi security: WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP, AES-CCMP, TKIP, Auto Cipher modes, client separation

Management, monitoring, configuration:

• Network features: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPSec, H.232 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
• Unique network features: VLAN, Mobile quota control, WEB Filter, Load Balancing, Network Backup, Auto Failover
• Connection monitoring: Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection, WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS
• Authentication: Busybox shell, Lua, C, C++

Special functions:
Card reader: None
I/O ports: 2 x SIM card slot
I/O ports: 1 x SFP
I/O ports: 1 x Console port (RJ-45)
I/O ports: 5 x 10/100/1000 Mbit/s
I/O ports: 1 x USB 2.0 Type A
SIM card: Mini
Power supply:

Dual 9-50 VDC, 4-pin DC connectors

Software:

RutOS (OpenWrt based Linux OS)

Certificates:
System Requirements:
Environment requirements:

• Operating temperature: -40°C to +75°C
• Humidity during operation: 10% to 90% non-condensing

Accessories included:

• RUTXR1
• 18W power supply
• 2 x LTE antenna (magnetic mounting, SMA plug, 3 m cable)
• 2 x WiFi antenna (magnetic mounting, RP-SMA plug, 1.5 m cable)
• Rack mounting kit
• 4 x pad
• 8 x screw
• SIM adapter kit
• Ethernet cable (1.5 m)
• QSG (Quick Start Guide)
• RMS leaflet

Color: Aluminium
Weight: 1050 gram
Dimensions:

272 x 42.6 x 122.6 mm

Other features:

• Network: 4G (LTE) Cat 6 DL up to 300 Mbps, UL up to 50Mbps, DC-HSDPA, HSUPA, WCDMA
• Processor: Quad Core ARM Cortex A7 717 MHz CPU
• Memory: 256 MB SPI Flash, 256 MB of DDR3 RAM

Designation:
