TELTONIKA Router LTE RUTX11 (Cat 6), WiFi, BLE

TELTONIKA Router LTE RUTX11 (Cat 6), WiFi, BLE

Model:

RUTX11

Description:

RUTX11 router

The RUTX11 router is an extremely efficient device with dual SIM slots, automatic switching, backup WAN and many software features. A wide range of interfaces allows this product to be used in energy-intensive industrial solutions where high Internet speeds and device reliability are expected. 4G LTE (CAT6) download speeds of up to 300 Mbps combined with four Gigabit Ethernet ports ensure smooth data transfer with automatic switching and WAN backup. Bluetooth Low Energy (BLE) sensors can be connected directly to the router, thus simplifying the ecosystem solution.

Type: GSM 3G/4G
Data transmission: LTE
Data transmission: UMTS
Data transmission: Bluetooth
UMTS network: 850 MHz
UMTS network: 900 MHz
UMTS network: 2100 MHz
UMTS network: 1800 MHz
LTE network: 2500 MHz
LTE network: 2100 MHz
LTE network: 2300 MHz
LTE network: 900 MHz
LTE network: 1500 MHz
LTE network: 1800 MHz
LTE network: 700 MHz
LTE network: 800 MHz
LTE network: 850 MHz
LTE network: 2600 MHz
Aero2 support: No
Standards: 802.3u
Standards: 802.3az
Standards: 802.3
Standards: 802.11n
Standards: 802.11ac
Standards: 802.11e
Standards: 802.11r
Standards: 802.11b
Standards: 802.11g
Operating frequency: 2,4 GHz
Operating frequency: 5 GHz
Number of antennas: Six connectors
Antenna: Detachable external
Security:

• Authentication: Pre-shared key, digital certificates, X.509 certificates
• Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T
• Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN,
• SYN-RST, X-mas, NULL flags, FIN scan attacks)
• VLAN: Port and tag based VLAN separation
• Mobile quota control: Custom data limits for both SIM cards
• WEB filter: Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
• Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
• WiFi security: WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP, AES-CCMP, TKIP, Auto Cipher modes, client separation

Management, monitoring, configuration:

• Mobile features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
• Network: Failover (Network backup), VLAN, QoS, Load Balancing
• Routing: Static routes, Dynamic routes (BGP, OSPFv2, RIPv1/v2, EIGRP, NHRP), Routing rules
• VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• Hotspot: External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
• NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator
• GNSS: NMEA forwarding, AVL, Geofencing

Special functions:
Card reader: None
I/O ports: 1 x USB 2.0
I/O ports: 2 x SIM card slot
I/O ports: 4 x 10/100/1000 Mbit/s
SIM card: Mini
Power supply:

4pin connector, 9-50 VDC

Software:

RutOS (OpenWrt based Linux OS)

Certificates:
System Requirements:
Environment requirements:

• Operating temperature: -40 C to 75 C
• Humidity during operation: 10% to 90% non-condensing

Accessories included:

• RUTX11 router
• 18W power supply
• 2 x LTE antenna (rotatable, SMA male)
• 2 x WiFi antennas (swivel, RP-SMA male)
• GNSS antenna (glued, SMA male, 3 m cable)
• Bluetooth antenna (magnetic mounting, RP-SMA male, 1.5 m cable)
• Ethernet cable (1.5 m)
• SIM Adapter kit
• Quick Start Guide
• RMS leaflet

Color: Aluminium
Weight: 456 gram
Dimensions:

115 x 44 x 95 mm

Other features:

• Network support: Mobile 4G/LTE (Cat 6), 3G
• CPU: Qualcomm, 4 x ARM Cortex A7, 717 MHz
• Memory: 256 MB Flash, 256 MB RAM
• GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
• Bluetooth: 4.0 BLE
• LED signaling: 4 x WAN, 2 x network type, 5 x signal strength, 2 x WiFi, 8 x Ethernet, power supply
• Housing: Aluminum, can be mounted on a DIN rail and can be grounded
