TELTONIKA Gateway TRB140 (Cat 4), 3G, 2G, PoE, USB

Model:

TRB140

Description:

TRB140 gateway

The TRB140 is an ultra-small, lightweight, energy-efficient LTE Cat 4 industrial network interface with a Gigabit Ethernet port, digital I/O connectors and a micro-USB interface.

Thanks to its compact design, this product is perfect for projects and solutions where you only need to connect one device to a reliable Internet connection.

The TRB140 is specifically designed for use in the industrial sector and has a wide range of software security features such as SMS control, firewall, open VPN, IPsec, Remote Management System (RMS) and FOTA support.

Type: GSM 3G/4G
Data transmission: LTE
Data transmission: UMTS
Data transmission: GPRS
GSM network: 1900 MHz
GSM network: 900 MHz
UMTS network: 2100 MHz
UMTS network: 900 MHz
LTE network: 700 MHz
LTE network: 900 MHz
LTE network: 1800 MHz
LTE network: 2100 MHz
LTE network: 2300 MHz
LTE network: 2500 MHz
LTE network: 2600 MHz
LTE network: 800 MHz
Aero2 support: No
Number of antennas: One connector
Antenna: Detachable external
Antenna gain: 2 dBi
Security:

• DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention)
• Firewall: Port forward, Traffic rules, Custom rules, Pre-configured firewall rules, DMZ, NAT, NAT-T, NAT helpers, Unlimited firewall configuration via CLI
• VPN: OpenVPN, IPsec, GRE, PPTP, L2TP

Management, monitoring, configuration:

• Mobile functions: Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
• Monitoring and management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• SMS functions: SMS status, SMS configuration, Send/Read SMS via HTTP POST/GET, EMAIL to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
• Services: DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging

Special functions:
Card reader: None
I/O ports: 1 x micro USB
I/O ports: 1 x 10/100/1000 Mbit/s PoE
I/O ports: 1 x SIM card slot
SIM card: Mini
Power supply:

4pin connector, 9-30 VDC

Software:

RutOS

System Requirements:
Accessories included:

• TRB140
• 4.5W power supply
• LTE antenna (magnet mounting, SMA male, 3m cable)
• Micro-USB cable (0.8 m)
• Assembly key
• LAN cable
• Quick start guide
• RMS leaflet

Color: Aluminium
Weight: 134 gram
Dimensions:

75 x 25 x 65 mm

Environment requirements:

• Operating temperature range: -40 °C to 75 °C
• Humidity during operation: 10 – 90% without condensation

Certificates:

• CE/RED
• EAC
• RoHS
• WEEE

Other features:

• Network support: 4G/LTE (Cat 4), 3G, 2G
• CPU: Qualcomm, ARM Cortex A7, 1.2 GHz
• Memory: 512 MB Flash (70 MB free), 128 MB RAM (50 MB free)
• Status LED: 3 x network type, 5 x signal strength, 2 x LAN, 1 x power
• Housing: Aluminum with the option of mounting on a DIN rail
• Degree of protection: IP30
• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
