Description:

The H9 Flow RGB+ is a spacious mid-tower ATX case designed for high-performance PC builds, combining effective cooling with aesthetics. Its dual-chamber design improves airflow and cable management, while perforated panels, angled fans, and ample support for fans and radiators ensure optimal thermal performance.

Key Features:

Dual-chamber design: Separates core components from the power supply and drives, improving thermal efficiency and simplifying cable management.

Optimized airflow: Perforated steel panels and angled fans on the front right side ensure efficient cooling for demanding builds.

RGB Ready: Includes two F420 RGB Core fans in a single-frame design, one F120 RGB Core (CV) fan in the rear, and an NZXT Control Hub controller.

CV = Case Version (3-pin DC)

Up to 10 Fan Capacity: Supports up to nine 140mm fans (top, front-right, bottom) and one 120mm fan in the rear.

Panoramic View: Showcase every detail of your build with a frameless tempered glass panel.

Supports Large Radiators and Graphics Cards: Accommodates radiators up to 420mm in the top and front-right, offering ample space for high-end graphics cards.

Easy Cable Management: Wide channels, built-in Velcro straps, and mounting points make cable management much easier.

Back-Connect Ready: Compatible with rear-connected motherboards like ASUS BTF and MSI Project Zero for a clean interior without visible cables.

Optimized Airflow

Angled fans in the front-right and an optimized internal layout keep temperatures low and performance high.

Mesh Panels

Ultra-permeable mesh panels maximize airflow while filtering dust.

Spacious Dual-Chamber Design

Separates heat-generating components, improving airflow and interior aesthetics.

10-Fan Cooling

Supports up to nine 140mm fans and one 120mm fan in the rear.

Large Radiator Support

Supports radiators up to 420mm on the top and front right panels.

Back-Connect Ready

Compatible with ASUS BTF and MSI Project Zero motherboards for a cable-free build.

Simple Cable Management

Wide channels, Velcro straps, and mounting points simplify cable management.

Controller Specifications

Fan Channels:

• 3 × NZXT 8-pin (PWM only)
• 1 × NZXT 8-pin (DC + PWM control)
• 1 × 4-pin PWM (DC + PWM control)

RGB Channels:

• 4 × NZXT 8-pin
• 1 × NZXT RGB

Maximum LED Support:

• Each NZXT 8-pin channel supports a maximum of 96 LEDs.
• The NZXT RGB channel supports up to 40 LEDs and a maximum of 5 NZXT devices.
