Netgear Netegar GSM4230PX switc h 24GE PoE+ 2GE 4SFP+

Netgear Netegar GSM4230PX switc h 24GE PoE+ 2GE 4SFP+

Description:

M4250-26G4XF-PoE+ (GSM4230PX)

24x1G PoE+ 480W 2x1G and 4xSFP+ managed switch

Switching designed for AV over IP 1 G technology with back-to-back ports for clean integration into AV racks. Pre-configured for operation out of the box!

Ground-breaking graphical user interface

Simplified user interface makes it easy to assign configuration profiles to each port.

Instant group broadcasting

The NETGEAR IGMP Plus feature enables group broadcasting immediately after unpacking for most AV over IP applications.

Sleek, quiet design

Lower fan noise and included mounting ears for under-table or wall installation.

Auto-configuration

Auto-trunk and auto-LAG function automatically connects to other M4250 (and M4300) switches.

Quick, easy – configuration for audiovisual professionals

Streamlined interface allows individual ports to be assigned AV factory defaults or user-specified AV profiles in just a few clicks

Focus on the event – no fan noise

Most models have a silent mode that significantly reduces fan noise, and some models are even fanless.

Audio and video over IP – right out of the box

With NETGEAR IGMP Plus technology built-in, video over IP configuration is unnecessary. Enable multicasting right out of the box.

Sophisticated design – allows installation

Clean lines and port activity status are shown on the front of the switch, and cabling is neat on the back. Universal mounting options allow mounting in a VESA rack or standard rack cabinets.

Switch class: Managed
Switch layer: L3
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 26
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: 4
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: 24
Number of COMBO ports: None
Number of SFP ports: None
Number of SFP+ ports: 4
Number of SFP56 ports: None
Number of QSFP+ ports: None
Console port: Yes
Forwarding mode: Store-and-forward
Throughput: 132 Gigabity na sek.
Forwarding rate: 98.21 Mpps
MAC address table size: 16000
Support for Jumbo frames: Yes
Jumbo frame size: 12 Kilobajt
Stackability: No
Number of VLAN groups: 4000
VLAN:
Supported protocols and standards:

• IEEE 802.3af (up to 15.4W per port)
• IEEE 802.3at (up to 30W per port)
• IEEE 802.3at Layer 2 (LLDP) method
• IEEE 802.3at 2-event classification

QoS:
Security:
Management, monitoring, configuration:
L2 features:
L3 features:
Other functions:
Chassis type: Rack
Fan : Yes
Power supply : Internal
Power consumption: 614 Watt
Mean time between failures (MTBF): 509057 Hour
Accessories included:
Power supply:
Dimensions:

440 x 43.2 x 400 mm

Weight: 5.45 kilogram
Other features:

Total PoE budget: 480W

Additional ports:

• Ethernet: 1G Out-of-band (Rear)
• Console: RJ45 RS232 (Rear)
• Console: USB-C (Rear)
• Storage: USB-A (Front)
• LED Ext: USB-C (Front)

Designation:
