Intellinet конвертор 10/100Base-TX RJ45

Intellinet конвертор 10/100Base-TX RJ45

Description:

Network Solutions Intellinet Fast Ethernet Media конвертор has been specifically designed to offer the network designer a device to migrate from a copper-to-Ethernet Ethernet network to fiber optic. Now, the migration or extension of existing networks can be achieved with minimal costs and complexity.

Usage: LAN
Special functions:
Accessories included:

• Media Fast Ethernet конвертор
• External power adapter
• User’s manual

Color: Black
Dimensions:

107 x 70 x 26 mm

Weight: 500 gram
Other features:

• Transmission media:
  – 100Base-TX Cat3 or better UPT / STP RJ45, EIA / TIA 568
  – 100Base-FX multi-mode 62.5 / 125 or 50/125 m
• Connectors:
  – 1 RJ45 port, 100Base-TX
  – 1 ST duplex fiber port, 100Base-FX
• Distances:
  – 2 km (for optical fiber 62.5 / 125 or 50/125)
  – 100 m (for an RJ45 Ethernet cable)
• Wavelength: 1310 nm
• Minimum sending power: -22 dBm
• Maximum transmission power: -12 dBm
• Receiver sensitivity: -30 dBm
• Signal loss: 2 dB / km
• Certificates: FCC Class B, CE Mark
