Cudy Switch GS1010PE 8 xGE PoE+ 120W 2xGb Uplink

Cudy Switch GS1010PE 8 xGE PoE+ 120W 2xGb Uplink

Description:

GS1010PE 10-Port Gigabit PoE+ Switch

• Total PoE budget up to 120 watts
• Up to 30 watts of PoE power from a single port
• 8 10/100/1000Mbps PoE+ ports
• 2 10/100/1000Mbps uplinks
• Complies with IEEE802.3af/at standards
• IEEE 802.3x flow control

Switch class: Unmanaged
Application: Home and small office
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 10
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: None
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: 8
Number of COMBO ports: None
Number of SFP ports: None
Number of SFP+ ports: None
Number of SFP56 ports: None
Number of QSFP+ ports: None
Console port: No
Forwarding mode: Store-and-forward
Throughput: 20 Gigabity na sek.
MAC address table size: 2000
Support for Jumbo frames: No
Stackability: No
VLAN:
Supported protocols and standards:

• IEEE802.3
• IEEE802.3u
• IEEE802.3x
• IEEE802.3ab
• IEEE 802.3af
• IEEE 802.3at

QoS:
Security:
Management, monitoring, configuration:
L2 features:
L3 features:
Other functions:
Chassis type: Rack
Chassis type: Desktop
Fan : No
Power supply : Internal
Power consumption: 120 Watt
Mean time between failures (MTBF): 100000 Hour
Accessories included:
Power supply:

Input: AC 100~240V

POE:

• Ports: 1-8
• Total PoE Budget: 120W
• Power for one port: 30W

Dimensions:

222 x 163 x 40 mm

Weight: 900 gram
Environment requirements:

• Operating temperature: -20°C ~ 50°C
• Storage temperature: -40°C ~ 80°C
• Operating humidity: 10% ~ 90% non-condensing
• Storage humidity: 5% ~ 90% non-condensing

Certificates:

• CE
• FCC Class A

Other features:
Designation:
