ATEN KVM Switch 8-Port USB 3.0 4k DP

ATEN KVM Switch 8-Port USB 3.0 4k DP

Description:

8-port USB 3.0 4K DisplayPort KVM switch

• Superior video quality – up to 4K DCI (4096 x 2160 @ 60Hz)
• Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rate
• Cascadable to two levels – control up to 128 computers
• Video DynaSync – ATEN’s exclusive technology that eliminates display problems at start-up and optimises resolution when switching between different sources.

The ATEN CS19208 8-port USB 3.0 4K DisplayPort KVM Switch allows you to access and control up to 8 DisplayPort computers with a single USB keyboard, USB mouse and monitor console. With the dual interface console, users can choose between DisplayPort/HDMI video outputs supporting high quality video resolutions up to 4K DCI (4096 x 2160 at 60 Hz) for crystal clear images.

To meet requirements for easy expansion and flexibility, the CS19208 can be cascaded up to two levels and control up to 128 computers from a single console. What’s more, the CS19208 supports a multi-display function, enabling information to be compared and analysed on up to eight monitors, greatly enhancing the working environment.

With ATEN’s two patented technologies – Video DynaSync and EDID Expert – the CS19208 can optimise display resolution, speed up switching between ports, and power on smoothly while eliminating monitor start-up issues.

In addition, the CS19208 is equipped with a built-in USB 3.1 Gen 1 hub that enables data transfer rates of up to 5Gbps, allowing users to speed up their workflow and make USB peripherals instantly available. To provide user-friendly port selection methods, the CS19208 offers pushbuttons, hotkeys, RS-232 commands and on-screen display (OSD) menus with a newly designed UI for easy and intuitive operation.

To eliminate security concerns, two-level password authentication is available to enhance the security of computer access and control. The consolidation of these beneficial features makes the CS19208 ideal for managing server/computer rooms used in industries where high image quality and multi-tasking are required, such as enterprise, government, manufacturing, telecommunications, financial, medical healthcare, industrial automation, etc.

No. of devices (max): 128
Console Ports: 2x Audio 3,5mm minijack Female
Console Ports: 1x HDMI Female
Console Ports: 1x DisplayPort Female
Console Ports: 2x USB Type A Żeński
Console Ports: 1 x RJ-11 Female
PC connectors: 8x Audio 3,5mm minijack Female
PC connectors: 8x USB Type B Female
Resolution: 4096 x 2160
Accessories included:

• CS19208 8-port USB 3.0 4K DisplayPort KVM switch with rack mount kit
• 2 x DisplayPort 1.4 cable
• 2 x USB 3.0 cable
• 2 x audio cable
• Cable for firmware update
• 4 x rubber feet
• Power adapter
• User manual

Dimensions:

432.4 x 214.3 x 44 mm

Weight: 3.11 kilogram
Functions:

• One USB console controls up to eight DisplayPort-enabled computers and two additional USB 3.0 peripherals
• Cascadable to two levels – control up to 128 computers1
• Multi-Display function – stack up to eight CS19208 units and display up to 8 monitors (dual / triple / quad / multiscreen)
• Video DynaSync – ATEN’s exclusive technology that eliminates display problems at start-up and optimises resolution when switching between different sources.
• EDID Expert – selects the optimal EDID mode for smooth power-ups and superior display quality
• DisplayPort or HDMI video output support – allows you to choose the right video output and deploy your console with flexibility
• Superior video quality – up to 4K DCI (4096 x 2160 @ 60Hz)
• Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rate
• Audio support – full bass response provides a rich experience for 2.1 channel stereo sound
• Supports HD2 audio
• Computer selection via buttons, keyboard shortcuts, OSD commands and RS-232
• Independent switching of KVM focus and USB peripherals3
• Two-level (administrator/user) password authentication for added security
• Broadcast mode – operations can be performed simultaneously on all selected computers, such as installing and updating software, shutting down the entire system, etc.
• Auto Scan mode for monitoring all computers
• Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
• Multilingual keyboard mapping – support for English (USA), English (UK), German (GER.), German (SWISS), French, Hungarian, Italian, Japanese, Korean, Russian, Swedish, Traditional Chinese and Simplified Chinese.
• Mac/Sun4 keyboard support and emulation
• Supports hot-plugging
• Compatible with DisplayPort 1.2, HDCP 2.2 compliant
• Multi-platform support – Windows, Linux, Mac and Sun
• Upgradable firmware
• Supports multimedia, wireless keyboards and mice

Other features:

For some RACK-mounted products, the standard dimensions width/depth/height may be expressed as length/width/height.
