AKYGA захранващ блок FLEX ATX200

AKYGA захранващ блок FLEX ATX200

Description:

Modern ITX power supply Akyga AK-I1-200 Pro series 200W, dedicated especially for mini-ITX cases like 1U case type. Commonly used both in ITX cases and racks.

The power supply is equipped with P4 4-pin connector, 2 x MOLEX connectors, 2 x SATA connectors and a universal 24-pin motherboard connector. Effective cooling is provided by efficient, silent fan of 4 cm diameter with automatic speed control. High efficiency above 70% allows effective supplying and so the stable operation of the power supply affects the reliability of all components of the computer.

An important aspect is the presence of several important protectors (OVP, OCP, OPP, OTP, SCP, UVP) and PFC filter that protects and prevents motherboard, processor and other parts from damage and stabilize the operat

Power supply: 200 W
Fan: 4 cm
PFC: Passive
MOLEX power connectors: 2
Floppy power connectors: 0
SATA power connectors: 2
Number of connectors PATA: 0
Number of power supply connector 4-pin 12V: 1
8-pin 12V power connectors: 0
Number of power supply connector 4+4-pin 12V: 0
PCI-E 6-pin power connectors: 0
Number of power supply connectors PCI-E 6 +2 pin: 0
PCI-E 8-pin power connectors: 0
Number of power connectors PCI-E 16-pin Gen 5: 0
Number of power connectors 12VHPWR: 0
Number of USB 10p connectors: 0
MB power connector: 24 pin
Modular power supply: No
Certificates 80+: None
Filters / protection: Thermal
Filters / protection: Circuit
Filters / protection: Current too high
Filters / protection: Automatic fan speed control
Filters / protection: Overload
Filters / protection: Surge
Accessories included:
Dimensions:

150 x 80 x 40 mm

Weight: 580 gram
Other features:

• FormatMini-ITX 1U
• Series Pro
• Supply voltage 230 V
• Power consumption< 2 A
• Efficiency> 70 %
• Current on the +3.3V rail8 A
• Current on the +5V rail10 A
• Maximum load on +3.3V and +5V line76 W
• Current on the +12V rail10 A
• Maximum load on 12V line120 W
• Power inlet IEC C14
• Ground wire
• Fan adjustments Automatic
• Cable length 40 cm
• Material Galvanized steel
• Product color Grey
• MTBF 100000 h
• Temperature 5 – 50 °C
• Package Foil
• Package size (L x W x H)211 x 101 x 41 mm
• Gross weight 587 g
• CE compatibility
• RoHS compatibility
• REACH compatibility
