Zyxel Switch XGS2220-54-EU0101 F L3, 24x1G RJ45 2x10mG

Zyxel Switch XGS2220-54-EU0101 F L3, 24x1G RJ45 2x10mG

Description:
Switch class: Managed
Application: Medium and large companies
Switch layer: L2
Switch layer: L3
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: 48
Number of 10/100/1000 Mbps ports: None
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: 2
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: None
Number of COMBO ports: None
Number of SFP ports: None
Number of SFP+ ports: 4
SFP28 ports: 1
Number of SFP56 ports: None
Number of QSFP+ ports: None
Console port: No
Forwarding mode: Store-and-forward
Throughput: 216 Gigabajty na sek.
Forwarding rate: 161 Megabajty na sek.
Packet buffer: 2 MegaBajt
MAC address table size: 32000
Support for Jumbo frames: No
Jumbo frame size: 9 Kilobajt
Stackability: Yes
VLAN:
Supported protocols and standards:

• IEEE 802.3z 1000BASE-X
• IEEE 802.3ab 1000BASE-T Ethernet
• IEEE 802.3an 10G BASE-T Ethernet
• IEEE 802.3ae 10 Gbit/s Ethernet over fiber
• IEEE 802.3af PoE
• IEEE 802.3at PoE plus
• IEEE 802.3bt (60 W) PoE over 4 pair
• IEEE 802.3az EEE
• IEEE 802.3x flow control
• IEEE 802.1AB LLDP/LLDP-MED
• IEEE 802.1Q VLAN tagging
• IEEE 802.1p Class of Service (CoS) prioritization
• IEEE 802.1X port authentication

QoS:

• No. of hardware queues per port (Standalone/stacking): 8/6
• Storm control and event log: Broadcast, multicast, unknown unicast (DLF)
• Port-based rate limiting (ingress/egress)
• Rate limiting per IP/TCP/UDP per port
• Policy-based rate limiting
• 802.3x flow control
• 802.1p Class of Service (SPQ, WFQ, WRR, hybrid-SPQ combination capable)
• DiffServ (DSCP)
• Storm Control: Broadcast/Unknown
• Multicast/Unknown Unicast (DLF)

Security:
Management, monitoring, configuration:

• SNMP v1, v2c, v3
• SNMP trap group
• RMON (1, 2, 3, 9)
• ICMP echo/echo reply
• Syslog
• IEEE 802.1AB LLDP*/LLDP-MED
• Custom default
• Syslog (IPv4/IPv6)
• Display port utilization
• Support NebulaFlex Pro for Cloud Management

L2 features:

• L2 multicast
• IGMP snooping (v1, v2, v3)
• IGMP snooping fast leave
• IGMP snooping immediate leave
• Configurable IGMP snooping timer and priority
• IGMP snooping statistics
• IGMP throttling
• IGMP filtering
• IGMP proxy mode & snooping mode selection
• Multicast load balance over trunking port
• Static mulitcast
• MVR support
• MLD snooping (MLD v1/v2)

L3 features:

• Max. 1 K IPv4 entries
• Max. 512 IPv6 entries

Other functions:
Chassis type: Rack
Fan : No
Power supply : Internal
Power consumption: 57.31 Watt
Mean time between failures (MTBF): 298.735 Hour
Accessories included:

• Power cord
• Rack mounting kit

Power supply:

100 – 240 V AC, 50/60 Hz

Dimensions:

441 x 270 x 44 mm

Weight: 3.85 kilogram
Other features:
Designation:
