Zyxel Switch XGS1930-28HP 24xGb PoE 4x10G SFP+ 375W

Zyxel Switch XGS1930-28HP 24xGb PoE 4x10G SFP+ 375W

Description:

XGS1930-28HP switch
The Smart Managed Switch series Zyxel GS1930 presents Zyxel NebulaFlex that allows you to easily switch between our license-free cloud management platform Nebula at any time in just a few simple clicks.

Switch class: Managed
Switch class: SMART
Application: Medium and large companies
Switch layer: L2
Network architecture: GigabitEthernet
Number of 10/100/1000 Mbps ports: 24
Number of PoE ports (PoE & PoE+): 24
Number of SFP+ ports: 4
Throughput: 128 Gigabajty na sek.
Forwarding rate: 95.2 Mpps
Packet buffer: 1.5 MegaBajt
MAC address table size: 16000
Stackability: Yes
VLAN:
Supported protocols and standards:

•    IEEE 802.3 10BASE-T Ethernet*
•    IEEE 802.3u 100BASE-TX Ethernet*
•    IEEE 802.3ab 1000BASE-T Ethernet*
•    IEEE 802.3z 1000BASE-X*
•    IEEE 802.3ae 10-Gigabit Ethernet Over Fiber*
•    IEEE 802.3af PoE*
•    IEEE 802.3at PoE Plus*
•    IEEE 802.3az EEE*
•    IEEE 802.3x flow control
•    IEEE 802.3ad LACP aggregation*
•    IEEE 802.1D Spanning Tree Protocol (STP)*
•    IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)*
•    IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
•    IEEE 802.1p Class of Service (CoS) prioritization*
•    IEEE 802.1X port authenticatio

QoS:

•    No. of hardware queues per port: 8*
•    802.1p queuing methods: SPQ, WRR, WFQ*
•    Storm control: broadcast, unknown L2MC, unknown unicast (DLF)*
•    Rate limiting per port
•    Policy-based rate limiting
•    Policy-based prioritizatio

Security:

•    802.1X*
•    Port security*
•    MAC authentication*
•    Static MAC forwarding
•    SSL
•    Static ARP
•    Policy-based security filtering
•    Port isolation
•    MAC search
•    Guest VLAN*
•    PPPoE relay agent
•    PPPoE option 82
•    PPPoE IA
•    Interface related trap enable/  disable (by port)
•    CPU protection
•    SHA2 HTTPS certification*
•    Login authentication by RADIUS*
•    RADIUS accounting
•    Authorization on RADIUS*
•    Multiple RADIUS servers*
•    802.1x VLAN and bandwidth  assignment by RADIUS*
•    ACL packet filtering (IPv4/IPv

Management, monitoring, configuration:

•    SNMP v1, v2c, v3
•    SNMP trap group
•    RMON (1, 2, 3, 9)
•    Syslog (IPv4/v6)*
•    IEEE 802.1AB LLDP
•    IEEE 802.1AB LLDP-MED
•    Custom default
•    Display port utilization*
•    Support NebulaFlex for hybrid mode

L2 features:

•    L2 multicast group: 1K
•    IGMP snooping (v1, v2, v3)*
•    Configurable IGMP snooping timer and priority
•    IGMP snooping statistics
•    IGMP throttling
•    IGMP filtering
•    Static multicas

L3 features:
Other functions:
Chassis type: Rack
Fan : No
Power supply : Internal
Power consumption: 471 Watt
Mean time between failures (MTBF): 1.369 Hour
Accessories included:

• Power cable
• Technical Documentation

Power supply:

100 to 240 V AC, 50/60 Hz

Dimensions:

441 x 330 x 44 mm

Weight: 4.6 kilogram
Other features:
Designation:
