UBIQUITI Networks UniFi Enterprise XG 24 Switch

UBIQUITI Networks UniFi Enterprise XG 24 Switch

Description:

Ubiquiti USW-EnterpriseXG-24 | Switch | 24x RJ45 10Gb/s, 2x SFP28 25G, L3

The Switch Enterprise XG 24 (USW Enterprise XG 24) is a fully managed, multi-gigabit Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports. The USW Enterprise XG 24 also features a 1.3-inch color touchscreen LCM that concisely displays key system and connection information.

Switch class: Managed
Application: Medium and large companies
Switch layer: L3
Switch layer: L2
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 24
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: None
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: None
Number of COMBO ports: None
Number of SFP ports: None
Number of SFP+ ports: None
SFP28 ports: 2
Number of SFP56 ports: None
Console port: No
Throughput: 290 Gigabity na sek.
Forwarding rate: 431.52 Mpps
Support for Jumbo frames: No
Stackability: No
VLAN:
Supported protocols and standards:
QoS:
Security:
Management, monitoring, configuration:
L2 features:

• IGMP Scanning
• STP/RSTP with Port Priority and Disablement
• Port Isolation
• Storm Control
• Voice VLAN
• Port Spinning
• LACP Port Aggregation
• Multicast/Broadcast Rate Limiting
• MAC Address Blocking
• Flow Control
• 802.1X Control
• Jumbo Frames
• Self Loop Protection
• DHCP Scanning/Detailed Scanning
• Egress Rate Limit
• LLDP-MED
• MAC Restricted Port
• Device Isolation with ACL

L3 features:

• DHCP for Locally Managed Networks
• DHCP Relay
• Routing Between VLANs on the Same Switch
• Static Routing Between Local Area Networks
• Network Isolation with ACLs

Other functions:
Chassis type: Rack
Fan : Yes
Power supply : Internal
Power consumption: 100 Watt
Environment requirements:

• Ambient operating temperature -5 to 40°C
• Ambient operating humidity 10% to 95% non-condensing

Certificates:

• CE
• FCC
• IC

Accessories included:
Power supply:

AC/DC, internal, 100W

Dimensions:

442 x 285 x 44 mm

Weight: 4.5 kilogram
Other features:

• 1.3″ color touch screen

Designation:
