TP-LINK SF1008D switch L2 8×10/100 Desktop

TP-LINK SF1008D switch L2 8×10/100 Desktop

Description:

The TL-SF1008D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 8 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play.

Features:

• Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode,
• Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum through,
• Fanless design ensures quiet operation,
• Desktop design,
• Plug and Play design simplifies installation.

Technical specifications:

HARDWARE FEATURES

Standards and Protocols
– IEEE 802.3,
– IEEE 802.3u,
– IEEE 802.3x,
– CSMA/CD
Interface 8 10/100Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
External Power Supply 100-240VAC, 50/60Hz
Fan Quantity Fanless
Data Rates 10/100Mbps at Half Duplex, 20/200Mbps at Full Duplex
LED Indicator Power, 1, 2, 3, 4, 5, 6, 7, 8
Dimensions ( W x D x H )5.3*3.1*0.9 in. (134.5*79*22.5mm)
Power Supply External Power Adapter

SOFTWARE FEATURES

Transfer Method Store and Forward
Advanced Functions Green Technology, saving power up to73% 802.3X Flow Control, Back Pressure, Auto-Uplink Every Port

OTHERS

Certification FCC, CE, RoHS
Package Contents
– 8-Port 10/100Mbps Desktop Switch
– Power Adapter
– User Guide
System Requirements Microsoft&#174, Windows&#174, 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8, Mac&#174, OS, NetWare&#174,, UNIX&#174, or Linux.
EnvironmentOperating Temperature 0&#176,C&#126,40&#176,C (32&#176,F&#126,104&#176,F),
Storage Temperature -40&#176,C&#126,70&#176,C (-40&#176,F&#126,158&#176,F),
Operating Humidity 10%&#126,90% non-condensing,
Storage Humidity 5%&#126,90% non-condensing
