TELTONIKA Router LTE RUTM09 (Cat6),2xSIM,1xWAN,3xLAN, 4xGbE,GNSS

TELTONIKA Router LTE RUTM09 (Cat6),2xSIM,1xWAN,3xLAN, 4xGbE,GNSS

Model:
Description:

The RUTM09 is a 4G LTE wireless router designed for applications requiring high cellular speeds. It is equipped with Category 6 and dual SIM cards, which allows the device to support speeds of up to 300 Mbps and features such as carrier aggregation and failover. Additionally, the RUTM09 has four gigabit RJ45 ports and GNSS, which enables GPS tracking for precise location determination. These features make the RUTM09 an excellent choice for ensuring uninterrupted network connectivity in mobile or tracking applications.

Type: GSM 3G/4G
Data transmission: LTE
Aero2 support: No
Standards: IPv4
Standards: IPv6
Standards: 802.3u
Standards: 802.3az
Standards: 802.3
Number of antennas: 3
Antenna: Detachable external
Security:

• Authentication: Pre-Shared Key, Digital Certificates, X.509 Certificates, TACACS+, Radius, IP and login blocking, time-based login blocking, built-in random password generator.
• Firewall: Ability to enable pre-configured firewall rules via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T.
• Attack Prevention: DDoS protection (SYN flood protection, SSH protection, HTTP/HTTPS protection), port scan protection (SYN-FIN attacks, SYN-RST attacks, X-mas, NULL flags, FIN scan attacks).

Management, monitoring, configuration:

• Web UI: HTTP/HTTPS support, status, configuration, firmware upgrade, CLI, troubleshooting, multiple event log server support, firmware upgrade notification, event log, system log, kernel log, internet status.
• FOTA: Firmware upgrade from server, automatic upgrade notification.
• SMS: SMS status, SMS configuration, send/receive SMS via HTTP POST/GET.
• Calls: Reboot, status, turn on/off mobile data, turn on/off output, answer/disconnect calls with timer.

Special functions:
Card reader: None
I/O ports: 2 x SIM card slot
I/O ports: 1 x WAN (RJ-45)
I/O ports: 3 x 10/100/1000 Mbit/s
SIM card: Mini
Power supply:

Input voltage range: 9-50 VDC, reverse polarity protection, surge protection >51 VDC, 10us max.

Software:

RutOS (OpenWrt based Linux OS)

Certificates:
System Requirements:
Environment requirements:

• Operating Temperature: -40°C to 75°C
• Operating Humidity: 10% to 90%, non-condensing

Accessories included:
Color: Black
Weight: 457 gram
Dimensions:

115 x 44.2 x 95.1 mm

Other features:
Designation:
