TELTONIKA Router LTE RUT241 (Cat 4), 2G ,WiFi, Ethernet

TELTONIKA Router LTE RUT241 (Cat 4), 2G ,WiFi, Ethernet

Model:

RUT241

Description:

ROUTER RUT241

RUT241 is a modified version of the bestseller RUT240, which inherits its best features, including industrial design, compact size, multiple connection interfaces and RMS compatibility.

Equipped with 4G LTE, Wi-Fi and two Ethernet ports, the router offers uninterrupted connection continuity with backup through automatic failover.

Digital inputs and outputs combined with advanced RutOS software enable the implementation of many solution automation scenarios.

RUT241 is a perfect fit for various IoT and M2M solutions that require easy configuration, reliable network and remote availability.

Type: GSM 3G/4G
Data transmission: EDGE
Data transmission: UMTS
Data transmission: LTE
GSM network: 900 MHz
GSM network: 1900 MHz
UMTS network: 850 MHz
UMTS network: 900 MHz
UMTS network: 2100 MHz
LTE network: 2300 MHz
LTE network: 2500 MHz
LTE network: 900 MHz
LTE network: 1800 MHz
LTE network: 2100 MHz
LTE network: 850 MHz
LTE network: 800 MHz
Aero2 support: No
Standards: 802.11b
Standards: IPv6
Standards: IPv4
Standards: 802.11n
Standards: 802.11g
Number of antennas:
Antenna: Detachable external
Security:

• DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention)
• Port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
• VPN: OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard
• WiFi security: WPA2-Enterprise – PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, Auto Cipher modes, client separation

Management, monitoring, configuration:

• Cellular Features: Auto APN, Band lock
• Network: Failover (Network backup), VLAN, QoS, Load Balancing
• Monitoring and management: WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS, Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• SMS: SMS status, SMS configuration, Send/Read SMS via HTTP POST/GET, EMAIL to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
• Services: DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging

Special functions:
Card reader: None
I/O ports: 1 x SIM card slot
I/O ports: 1 x 10/100 Mbit/s
I/O ports: 1 x 10/100 Mbit/s WAN
SIM card: Not applicable
Power supply:

4-pin connector, 9-30 VDC

Software:

utOS (OpenWrt based Linux OS)

System Requirements:
Accessories included:

• RUT241 router
• 9W power supply
• 2 x LTE antenna (swivel, SMA male)
• WiFi antenna (rotatable, RP-SMA male connector)
• Ethernet cable (1.5 m)
• SIM adapter (kit)
• Quick Start Guide
• RMS leaflet

Color: Black
Weight: 131 gram
Dimensions:

83 x 25 x 74 mm

Environment requirements:

• Operating temperature range: -40 °C to 75 °C
• Humidity range: 10-90% non-condensing

Other features:

• CPU: Mediatek MIPS 24Kc 580MHz
• Memory: 16 MB Flash, 128 MB RAM
• Power Consumption: < 6.5 W Max
• Antenna: 2x SMA cellular connector, female WiFi antenna connector (1 x RP-SMA)
• Status LED: 3 x network type, 5 x signal strength, 2 x Ethernet, 1 x power
• Housing: Aluminum with the option of mounting on a DIN rail
• Degree of protection: IP30
• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet

Designation:
