TELTONIKA Modem LTE TRM250 (Cat M1/NB), 2G, USB

TELTONIKA Modem LTE TRM250 (Cat M1/NB), 2G, USB

Description:

TRM250 cellular MODEM

The TRM250 is an industrial-grade cellular modem with multiple LPWAN connectivity options. It supports NB-IoT, LTE Cat-M1 and is backwards compatible with 2G.

It offers an exceptionally long life cycle, low power consumption and is the most flexible option when upgrading the connectivity of existing industrial equipment.

The TRM250 features a USB interface, a durable aluminum housing and an external antenna for better signal coverage.

Perfect for providing effective internet connectivity in remote monitoring applications.

Interface: USB
Data transmission: LTE
Data transmission: GPRS
GSM network: 850 MHz
GSM network: 900 MHz
GSM network: 1800 MHz
GSM network: 1900 MHz
LTE network: 2100 MHz
LTE network: 700 MHz
LTE network: 800 MHz
LTE network: 850 MHz
LTE network: 900 MHz
LTE network: 1700 MHz
LTE network: 1800 MHz
LTE network: 1900 MHz
SIM card: Mini
Antenna: Detachable external
Card reader: None
Aero2 support: No
Supported operating systems: Android
Supported operating systems: Windows 10
Supported operating systems: Windows 7
Supported operating systems: Windows 8.1
Supported operating systems: Windows 8
Supported operating systems: Linux
Accessories included:

• TRM250
• 1x cellular antenna (swivel SMA male)
• Micro-USB cable (0.8 m)
• Assembly key
• Quick start guide

Color: Aluminium
Dimensions:

74.5 x 25 x 64.5 mm

Weight: 130 gram
Environment requirements:

• Operating temperature range: -40 °C to 75 °C
• Operating humidity range: 10% to 90% non-condensing

Other features:

• Supported networks: 4G/LTE (Cat M1), NB-IoT, 2G
• Power supply: microUSB, 5 VDC
• Antenna connectors: SMA (cellular)
• USB: Micro USB slave
• LED Status: Network Status, Power
• Degree of protection: IP30
• Housing: Aluminum, DIN mounting option
• Control by AT commands: 3GPP TS27.007 (and enhanced AT commands)

Designation:
