TELTONIKA Managed switch TSW202 2xSFP 8xPoE+ Ethernet L2/L3

TELTONIKA Managed switch TSW202 2xSFP 8xPoE+ Ethernet L2/L3

Description:

TSW202 is the first managed industrial switch from Teltonika Networks, offering greater control over the flow of data on your network and the role of ports in your solution.

• PoE+ with a maximum power of 30 W per port and a total power of 240 W for PSE makes the TSW202 centralize power. PoE management gives you greater control over power distribution in your solution, allowing you to enable or disable PoE on selected ports.
• The switch is equipped with 8 Gigabit Ethernet LAN ports, allowing you to manage, configure and monitor your network. Additional software features, such as QoS, increase effective bandwidth management and the classification and prioritization of network traffic.
• Designed for industrial environments, the TSW202 features an integrated DIN rail mount, a robust aluminum housing, and resistance to extreme temperatures and vibration, ensuring maximum durability with ease of installation.

Switch class: Managed
Application: Home and small office
Switch layer: L2+
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 8
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: None
Number of PoE ports (PoE & PoE+): 8
Number of PoE+ ports: None
Number of COMBO ports: None
Number of SFP ports: 2
Number of SFP+ ports: None
Number of SFP56 ports: None
Console port: No
Throughput: 20 Gigabity na sek.
Packet buffer: 512 Kilobajt
MAC address table size: 8000
Support for Jumbo frames: Yes
Jumbo frame size: 10 Kilobajt
Stackability: No
VLAN:
Supported protocols and standards:

• IEEE 802.3af
• IEEE 802.3at

QoS:
Security:
Management, monitoring, configuration:
L2 features:
L3 features:
Other functions:
Chassis type: Desktop
Chassis type: Rack
Fan : No
Power supply : External
Power consumption: 240 Watt
Environment requirements:

Operating temperature: -40°C to 75°C

Certificates:

CE, CB, RCM, FCC, IC,EAC, UCRF

Accessories included:
Power supply:

• Input voltage range: 7 – 57 VDC
• Input voltage range for PoE: 44 – 57 VDC

Dimensions:

132 x 44.2 x 122.2 mm

Weight: 610 gram
Other features:
Designation:
