Netgear Switch Unmanaged Rack 16xGE – JGS516

Netgear Switch Unmanaged Rack 16xGE – JGS516

Description:

Switch series JGS500 Gigabit Switch NETGEAR to speed up your network while remaining within the specified budget. With the capacity of 32Gb / s you can send through a single port 2Gb / s data and the low price you can put the switch anywhere on the network providing gigabit connection directly to your desktop!
Based on the standards for the seamless integration of devices 10, 100 and 1000Mb / s, Rack JGS516 switch on each port has features such as Auto Uplink, or the ability to configure the full / half-duplex. This switch is ideal for workgroups, labs, small offices who want to transfer large multimedia files without sacrificing image on a significant cash.

The switch ProSafe 16 x 10/100/1000 Mb / s JGS516
16×10/100/1000 efficient bus at full capacity. Price low enough that it can be used at the network edge.

Additional information:
Technical specifications:

Port:

• &#160,&#160,&#160,&#160, JGS516: 16 x 10/100/1000 Mb / s

Performance

• &#160,&#160,&#160,&#160, Bandwidth: JGS516: 32 Gbps
• &#160,&#160,&#160,&#160, Frame transmission speed (1000 Mbps port): 1,480,000 pps
• &#160,&#160,&#160,&#160, Frame transmission speed (100 Mbps port): 148,000 pps
• &#160,&#160,&#160,&#160, Frame transmission speed (10 Mbps port): 14,800 pps
• &#160,&#160,&#160,&#160, Delay (1000 to 1000 Mbps): 20 &#297,S max
• &#160,&#160,&#160,&#160, Buffer: 2 MB
• &#160,&#160,&#160,&#160, Number of MAC addresses: 8,000
• &#160,&#160,&#160,&#160, Mean time between failures (MTBF): JGS516: 309.000 hours (&#126, 35 years)
• &#160,&#160,&#160,&#160, Noise: 40 dB

Energy consumption:
100-240V, 50-60 Hz
JGS524: 16max

Standards:
IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x
Status LEDs
Device: Power
Port: Link, Activity, Speed
physical Specifications
Dimensions (H x W x D): 43 x 330x 207 mm
Weight: JGS516: 1.62 kg,
Specification
Operating temperature: 0 &#176, to 50 &#176, C
Humidity: 90%
Storage temperature: -20 &#176, to 70 &#176, C
Electromagnetic Compatibility
CE mark, commercial
FCC Part 15 Class A
VCCI Class A
EN 55022 (CISPR 22), Class A, EN 50082-1,
EN 55024
C-Tick
security
UL listed (UL 1950) / cUL
IEC 950/EN 60950 System Requirements
XPressHW, Category 1: PRR0331

Included:

• JGS516
• Power Supply
• installation Instructions
• Installation Kit for Rack
• Card with information about the warranty

Designation:
