Netgear Switch 8xGE PoE+ 1xSFP GSM4210PD

Netgear Switch 8xGE PoE+ 1xSFP GSM4210PD

Description:

Ground-breaking AV GUI

Simplified user interface makes it easy to assign configuration profiles to each port.

Instant multicasting

NETGEAR IGMP Plus provides multicast functionality right out of the box for most AV over IP applications.

Sleek, quiet design

Lower fan noise and included mounting ears for under-table or wall mounting.

Automatic configuration

The auto-trunk and auto-LAG function automatically connects to other M4250 (and M4300) switches.

Quick, easy – configuration for professionals

The simplified interface allows you to assign factory AV settings or user-defined AV profiles to individual ports with just a few clicks.

Concentrate on the event, not the fan noise

Most models have a silent mode that significantly reduces fan noise, and some models are even fanless.

Designed for AV over IP right out of the box

With NETGEAR IGMP Plus technology built in, there is little or no configuration to ensure flawless video delivery over IP. Enable multicasting right out of the box.

Switch class: Managed
Application: Home and small office
Switch layer: L3
Switch layer: L2
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 9
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: None
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: 8
Number of COMBO ports: None
Number of SFP ports: 1
Number of SFP+ ports: None
Number of QSFP+ ports: None
Console port: No
Forwarding mode: Store-and-forward
Throughput: 20 Gigabity na sek.
Forwarding rate: 14.88 Mpps
Packet buffer: 16 MegaBajt
MAC address table size: 16000
Support for Jumbo frames: Yes
Jumbo frame size: 12 Kilobajt
Stackability: Yes
Number of VLAN groups: 4
VLAN:
Supported protocols and standards:

• IEEE 802.3af (up to 15.4W per port)
• IEEE 802.3at (up to 30W per port)
• IEEE 802.3at Layer 2 (LLDP) method
• IEEE 802.3at 2-event classification
• PoE timer / schedule (week, days, hours)

QoS:

• Supports ACLs (generic, includes IP ACLs)
• Supports MAC ACLs
• Access Lists
• L2 MAC, L3 IP and L4 Port ACLs
• Ingress
• Egress
• Time-based
• 802.3ad (LAG) for ACL assignment
• Binding ACLs to VLANs
• ACL Logging
• Support for IPv6 fields

Security:

• Password management
• Configurable VLAN for management
• Out-of-band management
• Century ACLs for separate management network
• Automatic installation
• (BOOTP and DHCP options 66, 67, 150 and 55, 125)
• Administrator access control via Radius and TACACS+
• Industry standard CLI (IS-CLI)
• CLI commands logged on Syslog server
• Web-based graphical user interface (GUI)

Management, monitoring, configuration:
L2 features:
L3 features:
Other functions:
Chassis type: Desktop
Fan : No
Power supply : Internal
Power consumption: 132.25 Watt
Mean time between failures (MTBF): 1020.808 Hour
Accessories included:

• M4250-9G1F-PoE+ (GSM4210PD)
• Power supply
• Power supply cable
• USB type C cable
• Flat brackets for desktop or wall mounting
• Rubber pads for table mounting
• Installation manual

Power supply:
Dimensions:

210x 140 x 40 mm

Weight: 965 gram
Other features:
Designation:
