Description:

Netgear GS724TPP SMART switch

Switches with essential L2 features for SMB networks

NETGEAR Smart Managed Pro switches feature L2 and L2+/Layer 3 Lite features, excellent PoE support and improved performance. They are designed for networks that use different types of multimedia, such as video, audio and data, within a single platform. Switches increase network efficiency, reduce network operating costs and facilitate management. These switches are also a perfect solution for cutting-edge small and medium-sized enterprises that are looking for an optimal combination of functionality, efficiency and quality.

Designed for large and small multimedia networks

• PoE and PoE+ support in every configuration
• VLAN with automatic voice data handling for fast and reliable VoIP telephony deployment
• VLAN with automatic video support, which, similarly to voice, allows you to accelerate the implementation of industrial camera infrastructure using the IP protocol
• Static routing helps redirect internal traffic and use network resources more efficiently
• IGMP and MLD protocol recognition provides advanced multicast filtering

With Netgear you will build a network ready for the challenges of the future

• High performance with non-blocking architecture, 256 VLANs, 100 shared ACL entries, 32 static routes and 512 multicast groups
• Comprehensive IPv6, QoS and ACL management ensures investment protection and smooth migration to IPv6 networks
• PoE+ support on all ports on GS510TLP, GS510TPP, GS418TPP, GS728TPv2, GS728TPPv2, GS752TPv2 and GS752TPP
• SFP ports provide fiber-optic connectivity, and dedicated SFP ports on many models provide additional connection performance
• Energy Efficient Ethernet (IEEE 802.3az) support provides greater energy savings for unused ports and short cables
• Advanced QoS with incoming IPv4/IPv6 filtering (ACL) and prioritization (QoS DiffServ)
• Dynamic VLAN assignment means convenient authentication and access to the network regardless of location

Convenient network deployment

• VLAN with automatic voice data handling for convenient implementation of VoIP telephony
• VLAN with automatic video support for convenient deployment of IP cameras
• The ACL wizard makes it easy to configure and access your network
• Smart Control Center discovers switches, making it easier to deploy, monitor and update firmware
• The PoE timer allows you to schedule power switching for PoE devices

A smart IT department doesn’t have to be big

• Convenient management within the browser interface or the Smart Control Center tool
• Standards-based technology ensures that any standard devices can be used on an existing network
• Duplicate firmware increases reliability and increases network uptime

Switch class: SMART
Application: Medium and large companies
Switch layer: L2+
Switch layer: L2
Switch layer: L3
Network architecture: GigabitEthernet
Number of 10/100/1000 Mbps ports: 24
Number of PoE ports (PoE & PoE+): 24
Number of SFP ports: 2
Forwarding mode: Store-and-forward
Throughput: 52 Gigabity na sek.
Forwarding rate: 38.6 Megabity na sek.
Packet buffer: 512 Kilobajt
MAC address table size: 8000
Support for Jumbo frames: Yes
Jumbo frame size: 9216 Kilobajt
Number of VLAN groups: 64
VLAN:
Supported protocols and standards:
QoS:

• Port-based rate limiting
• Port-based QoS
• Support for IPv6 fields
• DiffServ QoS
• IEEE 802.1p COS
• Destination MAC and IP
• IPv4
• TCP/UDP-based
• Weighted Round Robin (WRR)
• Strict priority queue technology

Security:
Management, monitoring, configuration:

• Cloud/Remote management
• Insight mobile app & Insight Cloud Portal management
• uPnP Discovery
• Networking monitoring
• Data/performance logs
• Centralized network configuration/policies (network-centric management)
• Device auto-join and configure (zero-touch provisioning)
• Multi-site, multi-network single pane-of-glass view Yes Multi-switch, multi-port concurrent configuration
• Network/global password (for all Insight Managed devices on a network) Yes
• Password management Yes IP Access List
• Configurable management VLAN
• Admin access control via RADIUS and TACACS+
• IPv6 management
• SNTP client over UDP port 123
• Firmware upgrade direct from Cloud (via mobile device or Insight Cloud portal)
• SNMP v1/v2c
• SNMP v3 with multiple IP addresses
• RMON group 1,2,3,9
• Smart Control Center (SCC) for multi-switch management
• Port mirroring
• Many-to-one port mirroring
• Cable test utility
• Ping and tracerout client

L2 features:

• IEEE 802.1Q VLAN tagging
• Protocol-based VLANs
• MAC-based VLANs
• Broadcast, multicast, unknown unicast storm control
• IEEE 802.3ad – LAGs (LACP)
• IEEE 802.3x (full duplex and flow control)
• IEEE 802.1D Spanning Tree Protocol
• IEEE 802.1w Rapid Spanning Tree Protocol
• IEEE 802.1s Multiple Spanning Tree Protocol
• IGMP snooping (v1, v2, and v3)
• IGMP snooping querier
• Block unknown multicast
• Multicast groups

L3 features:
Other functions:
Chassis type: Rack
Fan : Yes
Power supply : Internal
Power consumption: 32.71 Watt
Mean time between failures (MTBF): 634966 Hour
Environment requirements:
Certificates:
Accessories included:

• Power cable
• Mounting kit
• Rubber feet for countertop mounting
• Installation guide

Power supply:
Dimensions:

440 x 204 x 43 mm

Weight: 3.7 kilogram
Other features:
Designation:
