Description:
MEG Ai1300P PCIE5 power supply
- Supports Nvidia GeForce RTXTM 40 series graphics cards
- ATX 3.0 fully supported
- PCIe 5.0 ready with native 16-pin connector
- Software synchronization with MSI hub
- Fully modular design
- sleeve cables
- 80 PLUS Platinum certified for high performance
- 100% all Japanese 105oC capacitors
- Active PFC project
- Industrial level protection with OVP,OCP,OPP,OTP,SCP,UVP
- LLC half-bridge topology with DC-DC module design
Revelation of the legend
The MEG series has been revealed as a legend representing the ultimate in gaming elegance.
With a determination to push past current gaming products, flagship models push the boundaries of what an extreme gaming franchise can be. The mysterious triangle is a symbolic icon of MEG’s infinite power, and the slope of the triangle further extends the three pillars of MEG’s core features: Legendary, Loyal, and Luxurious.
ATX 3.0 Ready
It has a PCIe 5.0 and Intel PSDG (Power Supply Design Guide) ATX 3.0 compliant output port, and the power supply can withstand up to 2x total power spike and 3x GPU power spike.
Level up your game
With a native 16-pin PCIe connector, this power supply is ready to work with Nvidia GeForce RTX 40 series graphics cards. It can freely transfer up to 600W of power to PCIe 5.0 graphics cards.
80 PLUS Platinum CERTIFICATE
The efficiency of the power supply has a direct impact on system performance and power consumption. 80 PLUS Platinum certification promises lower energy consumption and higher performance.
Gaming intelligence
Gaming Intelligence aims to provide many unique and useful features to enhance the player experience.
GPU support for everyone
The power supply can support NVIDIA and AMD graphics cards. Prepared for the highest requirements, the MEG power supply IO brackets can support various and versatile connection ways according to the power connector design of different graphics cards.
Security and stability
The power supply is there to keep your system running smoothly under any load.
Compact size
Compared to the general platinum power supply on the market. At 160mm long and 150mm wide, the PSU fits snugly and easily into most PC cases, effectively allowing more space for cable management and airflow to the rest of your system.
fan design
Redefine the PSU fan design and optimize its usability as the best PSU operational support.
Power supply: 1300 W
Fan: 12 cm
PFC: Active
MOLEX power connectors: 4
Floppy power connectors: 1
SATA power connectors: 16
Number of power supply connector 4-pin 12V: 0
8-pin 12V power connectors: 1
Number of power supply connector 4+4-pin 12V: 1
PCI-E 6-pin power connectors: 0
Number of power supply connectors PCI-E 6 +2 pin: 8
PCI-E 8-pin power connectors: 0
MB power connector: 20 + 4 pin
Modular power supply: Yes
Dimensions:
160 x 150 x 86 mm
Certificates 80+: 80 PLUS Platinum
Accessories included:
Other features:
OCP/OVP/OPP/OTP/SCP/UVP protection
