EVER UPS SINLINE 1600VA/1040W L-inter. HID

EVER UPS SINLINE 1600VA/1040W L-inter. HID

Description:

The SINLINE series provides professional protection for small LANs, servers, workstations and DTP stations. Similarly to other Sinline UPS units, the SINLINE series features unique systems developed by EVER engineers: Clear Digital Sinus (CDS), a hardware digital system that generates, in mains and battery mode, a clear sine wave voltage in the UPS output, and Cool Battery Charging (CBC), a system that significantly extends the lifespan of batteries. Additionally, the series uses automatic mains voltage regulation (AVR) and USB communication interface.

Application: servers, PCs, computer terminals, device sensitive to power losses, telecommunication devices. SINLINE stands for intelligent and safe power supply for PCs, with guaranteed, clear sine wave in the output when operating in battery mode.

CHARACTERISTIC FEATURES

• CDS system – Clear Digital Sinus
• CBC system – Cool Battery Charging
• Cold start the possibility of starting the device without connection to the mains,

Apparent power: 1600 VA
Active power: 1040 Watt
UPS Architecture: line-interactive
Number of phases input: 1 (230V)
No. of batteries: 3
Voltage: 230 Volt
Battery capacity: 5 Ah
Hold-up time (maks): 3 millisecond
Backup time (100% load): 4 Minute
Charging time: 5 Hour
Chassis type: Tower
Filters / protection: Circuit
Filters / protection: Surge
Filters / protection: Overload
Special functions:

• CDS – Clear Digital Sinus
• CBC – Cool Battery Charging

Software:
Input power ports:
I/O connectors: 1 x USB (Type B)
I/O connectors: 2 x RJ-45 LAN
Environment requirements:

• Operating temperature [°C]:0 ÷ +40
• Operating / storage relative humidity: 20 – 80% / 20 – 95% (non-condensing)
• Altitude above sea level: up to 1000 m

Accessories included:
Color: Black
Dimensions:

190 x 165 x 480 mm

Weight: 17 kilogram
Other features:

• Output connections: 4 x PN-E-93201
• Protection degree: IP20

Designation:
