Digitus Docking Station SSD DA-71546

Digitus Docking Station SSD DA-71546

Description:

Manage M.2 NVMe and M.2 SATA SSDs via USB-C with integrated SD-Express card reader.

The DIGITUS 3-in-1 Docking Station allows you to dock M.2 SSDs with NVMe or SATA technology, and also features a DS-Express 7.1 card reader for the highest data transfer rate. Manage M.2 media with 4 TB per slot and SD cards up to 2 TB. NVMe SSD with B+M Key & M-Key and SATA SSD with B+M-Key are supported, each in formats 2242, 2260, 2280 & 22110. Easily expand the storage capacity of numerous USB-C devices such as computers, notebooks, TV equipment, consoles or routers.

• 1 x M.2 slot for NVMe SSD (B+M-Key / M-Key)
• 1 x M.2 slot for SATA SSD (B+M-Key)
• 1 x SD-Express 7.1 memory card reader max. 2 TB / max. 1000 MB/s
• High data transfer rate up to 10 Gbps (U.A.S.P + T.R.I.M support)
• Supports NVMe and SATA SSDs up to 4 TB
• Supported formats: 2242, 2260, 2280 i 22110
• Systems: Windows 10/8/8.1/7/XP, macOS 10.0 or later
• Can be used as total storage capacity up to 10TB
• Ideal storage extension for notebooks, PCs, consoles, TVs, NAS devices and routers (USB-C)
• Plug and Play, no drivers required

No. of slots: 2
Form factor (width): M.2 2280
Form factor (width): M.2 22110
Form factor (width): M.2 2242
Form factor (width): M.2 2260
Form factor (width): M.2
HDD interface: SATA
HDD interface: M.2
I/O connectors: 2 x USB (Type C)
Accessories included:

• 1 x USB A power adapter
• 1 x USB-C connection cable, 80 cm
• 1 x USB-C to USB A connection cable, 80 cm
• 1 x quick start guide

Color: Silver
Dimensions:

W 7.9 cm x D 7.7 cm x H 1.8 cm

Weight: 146 gram
Other features:

• Capacity: 4TB in one slot
• USB-C Connectors 1 x USB-C 3.2 Gen2 data, 1 x USB-C power
• Backwards compatible with USB 3.0 / USB 2.0 standard
• Maximum USB-C data transfer rate: 10 Gbps
• Supports U.A.S.P and T.R.I.M.
• Supports Hot Swap (slide in and out during operation)
• LED indicators for transfer to/from hard drive (white), to/from SD (blue) and power (green)
• Fields of application: PC, notebook, TV, router or gaming consoles (with USB-C connector)
• Data storage formats: NTFS, FAT, FAT32
• USB power supply input voltage: 100 -240 V AC, 50/60 Hz, 0.6 A – European plug: type C (CEE 7/16)
• USB power supply: 5 V / 3 A
• Material: ABS
