D-Link D-Link DGS-3130-30S Swi tch 24xSFP 2x10GB 4xSFP

D-Link D-Link DGS-3130-30S Swi tch 24xSFP 2x10GB 4xSFP

Description:

The DGS-3130 Series Gigabit Layer 3 Managed Switches are designed to meet the needs of small and medium-sized business networks by incorporating L2 and L3 features that enable the switches to be deployed in a variety of environments and topologies. Together, hardware and software enhancements create a family of powerful, flexible and cost-effective switches.

The DGS-3130 Series allows you to connect multiple switches to create a single physical or virtual stack. This increases redundancy across multiple physical units, simplifies management, and provides a single IP address to manage everything in the stack. The DGS-3130 Series includes the latest security features such as Multi-Layer and Packet Content Access Control Lists (ACLs), Storm Control, and IP-MAC-Port Binding (IMPB) with DHCP Snooping. The DGS-3130 series supports multiple authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC), ensuring tight access control and easy deployment. A rich set of multi-layered QoS/CoS features ensure that critical network services such as VoIP, video conferencing, IPTV and IP surveillance are always given high priority.

Switch class: Managed
Application: Medium and large companies
Switch layer: L3
Network architecture: GigabitEthernet
Number of 10/100 Mbps ports: None
Number of 10/100/1000 Mbps ports: 1
10/100/1000/2500 Mbps ports: None
Number of 10Gb ports: 2
Number of PoE ports (PoE & PoE+): None
Number of PoE+ ports: None
Number of COMBO ports: None
Number of SFP ports: 24
Number of SFP+ ports: 4
Number of SFP56 ports: None
Number of QSFP+ ports: None
Console port: Yes
Forwarding mode: Store-and-forward
Throughput: 168 Gigabajty na sek.
Forwarding rate: 125 Megabajty na sek.
Memory buffer: 2 MegaBajt
MAC address table size: 16000
Support for Jumbo frames: No
Jumbo frame size: 9 Kilobajt
Stackability: Yes
Maximum number of units per stack: 9
VLAN:

• Max. 4K VLAN Groups
• Max 1 ~ 4094 VIDs
• GVRP
• Max. 4K Dynamic VLAN Groups
• Dual VLAN (Q-in-Q)
• Based on Q-in-Q ports
• Selective Q-in-Q
• 802.1Q
• Auto Surveillance VLAN
• Port-based VLAN
• VLAN based on 802.1v protocol
• Voice VLAN
• MAC-based VLAN
• VLAN translation
• Multicast VLAN (ISM VLAN for IPv4/IPv6)
• Asymmetric VLAN
• Private VLAN
• VLAN Trunking
• Super VLAN

Supported protocols and standards:
QoS:
Security:
Management, monitoring, configuration:
L2 features:
L3 features:

• IPv4 ARP Entries 2048
• 512 Static ARP
• IPv6 ND Entries:1024
• 128 static entries NA
• IP interface
• Supports 16 interfaces
• Free ARP
• Feedback interface
• Proxy ARP
• Local ARP proxy support
• VRRP v2/v3
• IP Helper

Other functions:
Chassis type: Rack
Fan : Yes
Power supply : Internal
Power consumption: 82.4 Watt
Mean time between failures (MTBF): 487153 Hour
Environment requirements:
Certificates:
Accessories included:
Power supply:
Dimensions:

440 x 250 x 44 mm

Weight: 3.21 kilogram
Other features:
Designation:
