Cudy CUDY R700 Gigabit Multi -WAN VPN Router

Cudy CUDY R700 Gigabit Multi -WAN VPN Router

Model:

R700

Description:

Gigabit Multi-WAN VPN Router, R700

• 1 Gigabit WAN Port
• 3 Gigabit WAN/LAN Ports
• 1 Gigabit LAN Port
• Multi-WAN load balancing
• VPN Server PPTP/L2TP/OpenVPN/WireGuard/IPsec
• VPN Client PPTP/L2TP/OpenVPN/WireGuard/IPsec
• Zerotier for remote access and build a remote subnet
• DNS via Cloudflare/NextDNS/Google
• Extensive security mechanisms
• Compact and robust metal housing

Network media

• 10BASE-T: Category 3, 4, 5 UTP cable (max. 100 m)
• EIA/TIA-568 100 STP (max. 100 m)
• 100BASE-TX: Category 5, 5e UTP cable (max. 100 m)
• EIA/TIA-568 100 STP (up to 100 m)
• 1000BASE-T: Category 5e, 6 UTP cable (up to 100 m)

Type: xDSL
Network architecture: GigabitEthernet
I/O ports: 1 x WAN (RJ-45)
I/O ports: 4 x 10/100/1000 Mbit/s
Standards: 802.1Q
Standards: 802.3x
Standards: 802.3
Standards: 802.3ab
Standards: 802.3u
Security:

• IP/MAC/URL filtering
• Forcefully prevent viruses and intruder attacks
• Powerful firewall
• Advanced firewall rules protect your network and data
• Powerful firewall
• Reserves static IP addresses for clients to defend against ARP attacks and forgery
• DoS defence
• Automatically detects and blocks Denial of Service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death and other related threats
• One-click ALG activation
• One-click ALG activation for enemy applications such as FTP, H323, SIP, IPSec and PPTP

Management, monitoring, configuration:

TCP/IP, DHCP, ICMP, NAT, PPPoE,HTTP, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard, Zerotier

Special functions:
Power supply:

12 V/1 A

Software:
System Requirements:
Accessories included:
Color: Black
Dimensions:

119 x 85 x 28 mm

Other features:

• Flash: 16 MB NOR Flash
• DRAM: 128MB DDR
• LED: PWR, SYS, WAN (connection/activity), LAN (connection/activity)
