APC SMX2200RMHV2U X 2200VA USB/RS/LCD/RT 2U

APC SMX2200RMHV2U X 2200VA USB/RS/LCD/RT 2U

Description:

APC Smart-UPS X 2200VA Rack/Tower LCD 200-240V

APC Smart-UPS,1980 Watts /2200 VA, Input 208V, 230V/Output 230V, Interface Port SmartSlot, USB, Extended runtime model, Rack Height 2U

Apparent power: 2200 VA
Active power: 1980 Watt
UPS Architecture: line-interactive
Number of phases input: 1 (230V)
No. of batteries: 1
Voltage: 120 Volt
Battery capacity: 600 VAh
Backup time (100% load): 9.8 Minute
Charging time: 3 Hour
Chassis type: Rack
Chassis type: Tower
Special functions:

– Boost and Trim Automatic Voltage Regulation (AVR)
– Intelligent battery management
– Power conditioning
– Temperature-compensated battery charging
– Automatic restart of loads after UPS shutdown
– Automatic self-test
– Disconnected battery notification
– Network manageable
– Audible alarms
– LED status indicators
– Serial connectivity
– USB connectivity
– Disconnected battery notification
– User-replaceable batteries
– Hot-swappable batteries
– Predictive failure notification
– Resettable circuit breakers
– Battery failure notification
– Adjustable voltage-transfer points
– Adjustable voltage sensitivity
– Safety-agency approved

Software:
Input power ports: IEC-C20
Input power ports: Type G British
Input power ports: Type F Schuko
Output power ports: 1 x IEC-C19
Output power ports: 8 x IEC-C13
Connectors: SmartSlot
Connectors: 1 x USB (Typ B)
Environment requirements:

– Operating Environment: 0 – 45 &#176,C
– Relative Humidity: 0 – 95%
– The height above sea level Operating: 0-3000 m
– Temperature (storage): -15 – 45 &#176,C
– Relative humidity (storage) 0 – 95%
– The height above sea level (storage): 0-15000 m
– The noise level at 1 meter from surface of unit 55.00 dBA
– Thermal Dissipation 150.00 BTU/hr.

Accessories included:

– CD with software
– Rack Mounting brackets
– Smart UPS signalling RS-232 cable
– USB cable
– User Manual

Color: Black
Dimensions:

– Height: 85 mm
– Width: 432 mm
– Depth: 667 mm
– Rack Height 2U

Weight: 37.32 kilogram
Other features:

– Output Power: 1980W
– Output voltage: 208/220/230/240V
– Waveform Type: Sine wave
– 2 x IEC Jumpers
– Input voltage: 208/230V, 140-280V
– Cord Length: 1.83 m
– Power Switching time: 2-4 ms
– Emergency power supply
– Surge energy rating: 645 joules
